Tipper Dump Truck SINOTRUK HOWO A7 420HP 6X4 10 wheels 25 tons

Tipper Dump Truck SINOTRUK HOWO A7 420HP 6X4 10 wheels 25 tons

  • Tipper Dump Truck SINOTRUK HOWO A7 420HP 6X4 10 wheels 25 tons
  • Tipper Dump Truck SINOTRUK HOWO A7 420HP 6X4 10 wheels 25 tons
  • Tipper Dump Truck SINOTRUK HOWO A7 420HP 6X4 10 wheels 25 tons
  • Tipper Dump Truck SINOTRUK HOWO A7 420HP 6X4 10 wheels 25 tons
Tipper Dump Truck SINOTRUK HOWO A7 420HP 6X4 10 wheels 25 tons
Product Details:
Place of Origin: China
Brand Name: SINOTRUK HOWO A7
Certification: ISO/3C/BV/IFA/SGS
Model Number: ZZ3257V3847N1
Payment & Shipping Terms:
Minimum Order Quantity: 1 Unit
Price: USD42000-USD45000/UNIT)negotiation
Packaging Details: Nude or Waxing in Roro or bulk ship
Delivery Time: 25 working days after received your advance payment
Payment Terms: L/C, T/T, Western Union
Supply Ability: 3,000units per month
Contact Now
Detailed Product Description
Product Name: Tipper Dump Truck Model: ZZ3257N3847N1
Drive Type: LHD 6X4 Emission Standard: Euro 2
Engine: D12.42, 420HP Cargo Body: 5800*2300*1500mm
Loading Capacity: 30-40tons
High Light:

heavy dump truck

,

sinotruk howo dump truck

,

25tons SINOTRUK HOWO 6X4 Tipper Truck

Description:

This  product , witch have the characteristics of reanable structure , high loading capacity which can load 30-60tons,strong power of 420HP,reliable performance and wide acceplication.This model can meet the requirements of severe environment like construction site and mining area.which can fullfiled  you of short distance transportation of mining rock and soil as well as engineering construction.





Specification:



Tipper Dump Truck SINOTRUK HOWO A7 420HP 6X4 10 wheels 25 tons

Model ZZ3257V3847N1
Drive Type 6×4
Engine

D12.42 , 420HP( Euro II)

6 cylinder in-line with water cooling, turbo-charging & inter-cooling,4 stroke electronic fuel injection diesel engine

Displacement : 11.596L

Cabin A7-W lengthened cab(with one sleeper, air-conditioner and new-style seat)
Transmission HW19710(10 forwards & 2 reverses)
Front Axle 1×HF9 ( 9 Tons)
Driving Axle HC16, 16Tons
Steering ZF8118 hydraulic steering with power assistance.
Clutch Single-plate dry coil-spring clutch, diameter 430mm, hydraulically operating with air assistance
Rim/ Tire 11.00R20,12.00R20,12.00R24 Radial tire
Wheel base 3800+1350(mm)
Overall dimension 8575×2496×3450(mm)
Cargo body 5800×2300×1500(mm),Bottom:8mm, Side:6mm
The curb weight 12200(Kg)
Gross weight 25000 kg
Max. speed 75km/h
Color White, red, green, golden and so on.




Applications:



Suit for Mining industry, Construction business, docks, for transporting soil, sand, stones and so on.



Competitive Advantage:



1)reasonable cargo body structure , light weight , high rigidity , hight loading capacity

2)adopt the high strength steel,it has long service life

3)The perfect hydraulic control system helps to avoid wrong operation, it has higher safety and  running efficiency.

4)Multiple box structures and device selections

5)the whole truck structure has lower center of gravity,with higher security when lifting the cargo body.



Tipper Dump Truck SINOTRUK HOWO A7 420HP 6X4 10 wheels 25 tons 0

Tipper Dump Truck SINOTRUK HOWO A7 420HP 6X4 10 wheels 25 tons 1
