Durable Industrial Concrete Mixer Vehicle 8×4 High Running Efficiency

Durable Industrial Concrete Mixer Vehicle 8×4 High Running Efficiency

  • Durable Industrial Concrete Mixer Vehicle 8×4 High Running Efficiency
  • Durable Industrial Concrete Mixer Vehicle 8×4 High Running Efficiency
  • Durable Industrial Concrete Mixer Vehicle 8×4 High Running Efficiency
  • Durable Industrial Concrete Mixer Vehicle 8×4 High Running Efficiency
Durable Industrial Concrete Mixer Vehicle 8×4 High Running Efficiency
Product Details:
Place of Origin: China
Brand Name: SINOTRUK HOWO
Certification: ISO/3C/BV/IFA/SGS
Model Number: ZZ5311GJBN3261W
Payment & Shipping Terms:
Minimum Order Quantity: 1 Unit
Price: USD49500-USD50000/UNIT)negotiation
Packaging Details: Nude or Waxing in Roro or bulk ship
Delivery Time: 25 working days after received your advance payment
Payment Terms: L/C, T/T, Western Union
Supply Ability: 2,000units per month
Contact Now
Detailed Product Description
Product Name: Concrete Mixer Truck Model: ZZ5311GJBN3261W
Drive Type: LHD 8X4 Emission Standard: Euro 2
Engine: WD615.47, 371HP Tank Body Capacity: 14CBM
High Light:

Mobile Concrete Mixer Truck

,

truck mounted concrete mixer

Concrete Mixer Truck 14CBM SINOTRUK Golden Prince 336HP 8X4 LHD ZZ5311GJBN3261W



Description:



SINOTRUK HOWO Concrete Mixer Truck 14CBM 371HP 8X4 LHD ZZ5311GJBN3261W

The Concrete Mixer Truck series of products produced by adopt Germany's proprietary technology.

Products material requirements, the production process, acceptance criteria, all adopt the technology

provided by the German standards.



This products use the imported reducer, motor and hydraulic pump. Dynamic force output by the

second class chassis full power take off through the shaft power to the hydraulic pump, hydraulic

pump produces hydraulic energy through tubing to the hydraulic motor, hydraulic motor to convert

hydraulic energy into kinetic energy and through reducer then reduce and increase twist to the mixing

 tank, by adjusting the (double acting variable) servo controller of hydraulic pump Angle so as to realize

 controlling turning and speed of mixing drum, then to realize the concrete charging, stir and

discharging operation.





Specification:



SINOTRUK HOWO Concrete Mixer Truck 14CBM 371HP 8X4 LHD ZZ5311GJBN3261W

Model ZZ5311GJBN3261W
Drive Type 8×4
Engine

WD615.47 , 371HP( Euro II)

6 cylinder in-line with water cooling, turbo-charging & inter-cooling,4 stroke electronic fuel injection diesel engine

Displacement : 9.726L

Cabin L2000 lengthened cab(with one sleeper, air-conditioner and new-style seat)
Transmission HW19710(10 forwards & 2 reverses)
Front Axle 1×HF9 ( 9 Tons)
Driving Axle HC16, 16Tons
Steering D50 hydraulic steering with power assistance.
Clutch

Single-plate dry coil-spring clutch, diameter 430mm, hydraulically operating with

air assistance

Rim/ Tire 11.00R20,12.00R20,12.00R24 Radial tire
Wheel base 1800+3200+1350(mm)
Overall dimension 10150×2496×3950(mm)
Tank body Capacity

14CBM

The curb weight 14600(Kg)
Gross weight 31000 kg
Max. speed 102km/h
Color White, red, green, golden and so on.




Applications:



t’s suitable for agitating and transiting concrete, for construction site, road repairing and some other

 infrastructure construction business.



Competitive Advantage:



1) The leading product technology, complete function, excellent performance, reliable quality, easy to

   operate.

2) Optimization of body structure, special mold production, beautiful appearance, concrete mixing,

    discharge uniformity, low rate of residual.

3) Imported hydraulic pump, hydraulic motor and speed reducer.

4) Uses the high strength steel plate, long service life.

5) Optimization of the whole structure, low center of gravity, high running efficiency.

6) Product range is wide, the tank capacity of 6 to 18 cubic meters.

7) Choose a variety of auxiliary device.

8) Match all concrete mixer truck chassis.

9) based on strong technical support and top level technology make the trucks with high

quality and more reliable
10) competive price, cost-effective
11) quick and efficient spare parts supply bring you more convenient
12) fast delivery time, we can arange production according to your needs exactly and

     quickly

13) professional import and export dealing precedure, make customs clearance more high efficiency
