Home ProductsConcrete Mixer Truck

mobile Concrete Mixer Truck with pump , 10 CBM Trailer Concrete Mixer

mobile Concrete Mixer Truck with pump , 10 CBM Trailer Concrete Mixer

  • mobile Concrete Mixer Truck with pump , 10 CBM Trailer Concrete Mixer
  • mobile Concrete Mixer Truck with pump , 10 CBM Trailer Concrete Mixer
  • mobile Concrete Mixer Truck with pump , 10 CBM Trailer Concrete Mixer
  • mobile Concrete Mixer Truck with pump , 10 CBM Trailer Concrete Mixer
mobile Concrete Mixer Truck with pump , 10 CBM Trailer Concrete Mixer
Product Details:
Place of Origin: China
Brand Name: SINOTRUK HOHAN
Certification: ISO/3C/BV/IFA/SGS
Model Number: ZZ5255GJBN3846B1
Payment & Shipping Terms:
Minimum Order Quantity: 1 Unit
Price: USD49500-USD50000/UNIT)negotiation
Packaging Details: Nude or Waxing in Roro or bulk ship
Delivery Time: 25 working days after received your advance payment
Payment Terms: L/C, T/T, Western Union
Supply Ability: 2,000units per month
Contact Now
Detailed Product Description
Product Name: Concrete Mixer Truck Model: ZZ5255GJBN3846B1
Drive Type: RHD 6X4 Emission Standard: Euro 2
Engine: WD615.69, 336HP Tank Body Capacity: 10CBM
High Light:

Mobile Concrete Mixer Truck

,

truck mounted concrete mixer

SINOTRUK HOHAN Concrete Mixer Truck 10CBM Euro2 336HP 6X4 RHD ZZ5255GJBN3846B1



Description:



Concrete Mixer Truck 10CBM SINOTRUK HOHAN Euro2 336HP 6X4 RHD ZZ5255GJBN3846B1

The Concrete Mixer Truck series of products produced by adopt Germany's proprietary technology.

Products material requirements, the production process, acceptance criteria, all adopt the technology

provided by the German standards.



This products use the imported reducer, motor and hydraulic pump. Dynamic force output by the

second class chassis full power take off through the shaft power to the hydraulic pump, hydraulic pump

produces hydraulic energy through tubing to the hydraulic motor, hydraulic motor to convert hydraulic

energy into kinetic energy and through reducer then reduce and increase twist to the mixing tank, by

adjusting the (double acting variable) servo controller of hydraulic pump Angle so as to realize

controlling turning and speed of mixing drum, then to realize the concrete charging, stir and discharging

operation.





Specification:



SINOTRUK HOHAN Concrete Mixer Truck 10CBM Euro2 336HP 6X4 RHD ZZ5255GJBN3846B1

Model ZZ5255GJBM3846B1
Drive Type 6×4
Engine

WD615.69 , 336HP( Euro II)

6 cylinder in-line with water cooling, turbo-charging & inter-cooling,4 stroke electronic fuel injection diesel engine

Displacement : 9.726L

Cabin H16 lengthened cab(with one sleeper, air-conditioner and new-style seat)
Transmission HW19710(10 forwards & 2 reverses)
Front Axle 1×HF9 ( 9 Tons)
Driving Axle HC16, 16Tons
Steering ZF8098 hydraulic steering with power assistance.
Clutch

Single-plate dry coil-spring clutch, diameter 430mm, hydraulically operating with air

assistance

Rim/ Tire 11.00R20,12.00R20,12.00R24 Radial tire
Wheel base 3825+1350(mm)
Overall dimension 9090×2496×3950(mm)
Tank body Capacity

10CBM

The curb weight 13010(Kg)
Gross weight 25000 kg
Max. speed 102km/h
Color White, red, green, golden and so on.




Applications:



t’s suitable for agitating and transiting concrete, for construction site, road repairing and some other

infrastructure construction business.



Competitive Advantage:



1) The leading product technology, complete function, excellent performance, reliable quality, easy to

   operate.

2) Optimization of body structure, special mold production, beautiful appearance, concrete mixing,

    discharge uniformity, low rate of residual.

3) Imported hydraulic pump, hydraulic motor and speed reducer.

4) Uses the high strength steel plate, long service life.

5) Optimization of the whole structure, low center of gravity, high running efficiency.

6) Product range is wide, the tank capacity of 6 to 18 cubic meters.

7) Choose a variety of auxiliary device.

8) Match all concrete mixer truck chassis.

9) based on strong technical support and top level technology make the trucks with high

quality and more reliable
10) competive price, cost-effective
11) quick and efficient spare parts supply bring you more convenient
12) fast delivery time, we can arange production according to your needs exactly and

     quickly

13) professional import and export dealing precedure, make customs clearance more high efficiency
