Home ProductsSemi Trailer Truck

Semi Flatbed Trailers Refrigerated Transport Vehicle Carbon Steel / Mn Steel Material

Semi Flatbed Trailers Refrigerated Transport Vehicle Carbon Steel / Mn Steel Material

    • Semi Flatbed Trailers Refrigerated Transport Vehicle Carbon Steel / Mn Steel Material
    • Semi Flatbed Trailers Refrigerated Transport Vehicle Carbon Steel / Mn Steel Material
    • Semi Flatbed Trailers Refrigerated Transport Vehicle Carbon Steel / Mn Steel Material
    • Semi Flatbed Trailers Refrigerated Transport Vehicle Carbon Steel / Mn Steel Material
  • Semi Flatbed Trailers Refrigerated Transport Vehicle Carbon Steel / Mn Steel Material

    Product Details:

    Place of Origin: China
    Brand Name: SINOTRUK
    Certification: ISO/3C/BV/IFA/SGS
    Model Number: 3 Axles 30-60Tons

    Payment & Shipping Terms:

    Minimum Order Quantity: 1 Unit
    Price: Negotiation
    Packaging Details: Nude or Waxing in Roro or bulk ship, or by 40GP, 40HQ,40FR and so on
    Delivery Time: 20 working days after received your advance payment
    Payment Terms: L/C, T/T, Western Union
    Supply Ability: 4,000units per month
    Detailed Product Description
    Product Name: Refrigerated Semi Trailer Truck Model: 3 Axles 30-60Tons
    Fifth Wheel: #50, #90 Loading Capacity: 30-60tons
    Dimension Of Flat: 12600*3000mm Axles: 3X16 Tons
    Material: Carbon Steel Or Mn Steel Landing Gear: 28T JOST

    Refrigerated Semi Trailer Truck 20 or 40 Feet Container 2 or 3 Axles 30-60 Tons



    Description:



    Refrigerated Semi Trailer Truck 20 or 40 Feet Container 2 or 3 Axles 30-60 Tons

    Refrigerated truck is one kind of closed van truck which is used to transport the frozen

    or fresh goods, was fitted with the refrigerating unit device and polyurethane thermal

    insulation van and it is refrigeration special use transport truck,



    usually used for transporting frozen foods ( freezer truck ), dairy ( milk truck ), vegetables and fruits

    ( fresh goods transport vehicle ), vaccine and drug ( vaccine vehicles) etc.



    Our company produces flat semitrailer divided into flat, concave beam and tire exposed structure,

    beam adopts flat type or goose neck. The frame is ladder type, the beam cross-section is

    I-shaped, has high anti breaking strength and bearing capacity.





    Specification:



    Refrigerated Semi Trailer Truck 20 or 40 Feet Container 2 or 3 Axles 30-60 Tons

    Model 3 Axles 60Tons
    Axle

    FUWA brand, 16ton, 2 Sets

    Main beam

    Beam height: 500mm

    Upper plate: 10mm

    Double Middle plate: 6 mm

    Down plate: 12mm

    Dimension of cargo body

    13000*2335*2390mm

    Van board material

    polymer composites

    Gross vehicle weight

    70000kgs

    King pin

    #90

    Support leg

    JOST Standard 28T

    Suspension

    Normal suspension

    Thickness leaf spring

    10/10/10

    Tire/Rim

    1200R20, 13pcs, 8.5, 12 pcs

    Brake Chamber

    Standard 6 pcs

    Spare wheel carrier

    2 pcs

    Tool box

    1 pcs

    Electrical System

    Chinese standard 24C lighting system

    Side Maker Lamp

    LED lamp

    Painting

    Polyurethane Paint

    Overall dimension

    16000×2500×3880(mm)

    Color White, red, green, golden and so on.








    Applications:



    Refrigerated semi trailer Truck can widespread use in transportation of all kind of frozen food, vaccinum, vegetables and fruit.



    Competitive Advantage:



    1) competitive price, cost-effective

    2) quick and efficient spare parts supply bring you more convenient

    3) fast delivery time, we can arrange production according to your needs exactly and Quickly

    4) professional import and export dealing procedure, make customs clearance more high efficiency

    5) Refrigeration, heat preservation car body with light, high strength, good heat

    insulation performance, high temperature stability, no pollution, oxidation, easy

    maintenance, but also has low noise, low energy consumption, low failure rate, food

    preservation effect is good and so on a series of advantages
    6) A lot of technical indicators and the world's advanced level is close to the fully

    closed polyurethane plate bonded glass steel structure, this product is light weight,

    low heat leakage.

    7) The "sandwich" structure (low thermal conductivity), good thermal

    insulation effect. Using unsaturated polyester resin as binder, plus a cushion, with

    rigid polyurethane foam insulation, heat conduction low coefficient, high strength. High

    strength plate bonding, high sealing glue, forming a whole. The structure of the

    refrigerator car is dominant in the domestic market, our company is using the technology

    of refrigerated trucks.

    8) Our company's production of circular easy brand refrigerator car introduced Italy,

    Germany, the United States overall polyester foam technology, and high strength fiber

    plastic and other material manufacturing technology and equipment
    9) so that our company refrigeration, heat preservation technology level basic reached

    world advanced water level.

    10)Using three axis balance, double axis balance or rigid suspension, the mass balance block is

    arranged between the front and rear leaf springs.

    11) the key parts adopt the world's top technology products

    12)based on strong technical support and top level technology make the trucks with high quality and

    more reliable



    Semi Flatbed Trailers Refrigerated Transport Vehicle Carbon Steel / Mn Steel MaterialSemi Flatbed Trailers Refrigerated Transport Vehicle Carbon Steel / Mn Steel Material
