Large Capacity Diesel Semi Trailer Truck / Fuel Tanker Truck 14100 * 2500 * 3780 mm

Large Capacity Diesel Semi Trailer Truck / Fuel Tanker Truck 14100 * 2500 * 3780 mm

    • Large Capacity Diesel Semi Trailer Truck / Fuel Tanker Truck 14100 * 2500 * 3780 mm
    • Large Capacity Diesel Semi Trailer Truck / Fuel Tanker Truck 14100 * 2500 * 3780 mm
    • Large Capacity Diesel Semi Trailer Truck / Fuel Tanker Truck 14100 * 2500 * 3780 mm
    • Large Capacity Diesel Semi Trailer Truck / Fuel Tanker Truck 14100 * 2500 * 3780 mm
  • Large Capacity Diesel Semi Trailer Truck / Fuel Tanker Truck 14100 * 2500 * 3780 mm

    Product Details:

    Place of Origin: China
    Brand Name: SINOTRUK
    Certification: ISO/3C/BV/IFA/SGS
    Model Number: 3 Axles 50000 Liters Oil carrying Trailer

    Payment & Shipping Terms:

    Minimum Order Quantity: 1 Unit
    Price: Negotiation
    Packaging Details: Nude or Waxing in Roro or bulk ship, or by 40GP, 40HQ,40FR and so on
    Delivery Time: 20 working days after received your advance payment
    Payment Terms: L/C, T/T, Western Union
    Supply Ability: 4,000units per month
    Contact Now
    Detailed Product Description
    Product Name: Semi Trailer Oil Tank Truck Model: 3 Axles 50000Liters
    Fifth Wheel: #50, #90 Loading Capacity: 50-80tons
    Tank Capacity: 45-60CBM Thickness Of Tank Body: 4mm 5mm 6mm Optional
    Axles: 3X13 Tons,3X16 Tons Material: Carbon Steel Or Mn Steel
    Compartment: Single

    SINOTRUK Large Capacity Diesel Semi Trailer Tanker truck Tri - Axle 50 - 80 Tons



    Description:



    SINOTRUK Large Capacity Diesel Semi Trailer Tanker truck Tri - Axle 50 - 80 Tons

    Semi trailer is divided into two parts, the tank section and the support of the frame of the tank or moving parts,

    Semi trailer rear is roughly the same, after double (two), after the bridge (three axis) of the points, according to the need to select the traction head. Usually in the traction head brand name of Semi Trailer

    I Semi Trailer

    Semi trailer tank

    1, the tank using Steel Corp production of 4mm or 6mm high quality carbon steel according to the national standard, the shape of oval or square round body, can be installed 1-4 kinds of oil. Also can produce heating insulation series tank.

    2, alcohol, chemical tank of imported stainless steel, thickness of 4mm-5mm.

    3, all kinds of hydrochloric acid, sulfuric acid, lye tank with plastic production, the thickness of 12mm - 22mm.

    4, tank equipped with multi-channel anti wave partition. Using high pressure gas leakage detection, the tank has a high intensity, stable center of gravity, safe and stable vehicle.

    5, according to the use of tank can choose centrifugal pump, gear pump, stainless steel pumps, with the flow, suction speed and so on.

    6, the oil tank can be selected from single counting, double counting flow meter, can also be equipped with control computer tankers, install the 10-15 meter automatic telescopic return reel, equipped with gas gun. Edible oil can choose edible oil computer meter.







    Specification:



    SINOTRUK Large Capacity Diesel Semi Trailer Tanker truck Tri - Axle 50 - 80 Tons
    Model 3 Axles 50000Liters
    Axle

    FUWA brand, 13ton, 3 Sets

    Main beam

    Beam height: 500mm

    Upper plate: 10mm

    Double Middle plate: 6 mm

    Down plate: 12mm

    Tank Body Thickness

    4mm, 5mm, 6mm optional

    Material

    Carbon steel or Mn steel

    Gross vehicle weight

    65000kgs

    King pin

    #90

    Support leg

    JOST Standard 28T

    Suspension

    Normal suspension

    Thickness leaf spring

    10/10/10

    Tire/Rim

    1200R20, 13pcs, 8.5, 12 pcs

    Brake Chamber

    Standard 6 pcs

    Spare wheel carrier

    2 pcs

    Tool box

    1 pcs

    Electrical System

    Chinese standard 24C lighting system

    Side Maker Lamp

    LED lamp

    Painting

    Polyurethane Paint

    Overall dimension

    14100×2500×3780(mm)

    Color White, red, green, golden and so on.




    Applications:



    It’s suitable for storage and carrying all kinds of Oils .



    Competitive Advantage:



    1) it has higher safety and running efficiency.

    2) Optimized structure design, let it have lower self weight, but more stonger

    3) excellent appearance of cabin, safety, reliable

    4) low fuel consumption

    5) the key parts adopt the world's top technology products

    6) based on strong technical support and top level technology make the trucks with high

        quality and more reliable

    7) competitive price, cost-effective

    8) quick and efficient spare parts supply bring you more convenient

    9) fast delivery time, we can arrange production according to your needs exactly and Quickly

    10) professional import and export dealing procedure, make customs clearance more high efficiency
