HOWO Drawing Head Tractor Truck LHD 6x4 371HP Single Berth Cabin Air Suspension

HOWO Drawing Head Tractor Truck LHD 6x4 371HP Single Berth Cabin Air Suspension

    • HOWO Drawing Head Tractor Truck LHD 6x4 371HP Single Berth Cabin Air Suspension
    • HOWO Drawing Head Tractor Truck LHD 6x4 371HP Single Berth Cabin Air Suspension
    • HOWO Drawing Head Tractor Truck LHD 6x4 371HP Single Berth Cabin Air Suspension
    • HOWO Drawing Head Tractor Truck LHD 6x4 371HP Single Berth Cabin Air Suspension
  • HOWO Drawing Head Tractor Truck LHD 6x4 371HP Single Berth Cabin Air Suspension

    Product Details:

    Place of Origin: Jinan, China
    Brand Name: SINOTRUK HOWO
    Certification: ISO/3C/BV/IFA/SGS
    Model Number: ZZ4257S3241W

    Payment & Shipping Terms:

    Minimum Order Quantity: 1 Unit
    Price: USD36500-USD37000/UNIT)negotiation
    Packaging Details: Nude or Waxing in Roro or bulk ship
    Delivery Time: 20 working days after received your advance payment
    Payment Terms: L/C, T/T, Western Union
    Supply Ability: 4,000units per month
    Contact Now
    Detailed Product Description
    Product Name: Tractor Truck/Towing Truck/Prime Mover Model: ZZ4257S3241W
    Drive Type: LHD 6X4 Emission Standard: Euro 2 Or Euro3
    Engine: D12.38, 380HP Fifth Wheel: #90
    Traction Capacity: 60-100tons Color: According To Your Requests

    HOWO Drawing Head Tractor Truck LHD 6x4 371HP single berth cabin air suspension



    Description:



    HOWO Drawing Head Tractor Truck LHD 6x4 371HP single berth cabin air suspension

    High strength/ high rigidity/ long life block: vermicular cast iron body, similar strength cast steel, similar heat dissipation potential gray iron, strong anti-thermal deformation, high cost, can be adopted in few high end engines in the world due to its core technology.



    1). Good economy: high-explosive pressure and optimized injection and combustion system, ensuring its low specific oil consumption at a wide range of sppds, Minimum specific oil consumption is 186/kwh.



    2). Low nose: noise reaches the international level.



    3). High-integration: volume of spare parts reduced 25% compared with the similar products in the world, highly reducing the failure points.



    4). Long life of B10: reach the most advanced world level of heavy duty truck, 1.5 million km.



    5). Long oil change interval: for Euro IV oil, the first oil change mileage( oil change interval) for the road vehicles since left factory shall be up to 100.000 km, for the oil selling bu Petrochina and Sinopec. it shall be up to 60.000 km, greatly reducing the cost.



    Specification:



    HOWO Drawing Head Tractor Truck LHD 6x4 371HP single berth cabin air suspension

    Model ZZ4257S3241W
    Drive Type 6×4
    Engine

    D12.38 , 380HP( Euro II)

    6 cylinder in-line with water cooling, turbo-charging & inter-cooling,4 stroke electronic fuel injection diesel engine

    Displacement : 11.596L

    Cabin HW76(with single sleeper, air-conditioner and new-style seat)
    Transmission HW19710(10 forwards & 2 reverses)
    Front Axle 1×HF9 ( 9 Tons)
    Driving Axle HC16, 16Tons
    Steering ZF8098 hydraulic steering with power assistance.
    Clutch

    Single-plate dry coil-spring clutch, diameter 430mm, hydraulically operating

    with air assistance

    Rim/ Tire

    12R22.5 tubeless tyre

    11.00R20,12.00R20,12.00R24 Radial tire
    Wheel base 3200+1350(mm)
    Overall dimension

    6800×2496×2958(mm)

    Fifth Wheel

    #50, #90

    The curb weight 9180(Kg)
    Gross weight 25000 kg
    Max. speed 102km/h
    Color White, red, green, golden and so on.




    Applications:



    It’s suitable for towing all kinds semi trailer which is used in Logistics business, construction site and

    Mining area .



    Competitive Advantage:



    1.We are professional manufacturers to do the special vehicles ,such as fire truck ,

    wrecker tow truck, aerial work platform truck, water tank truck, fuel tank truck ,refrigerator truck,mixer
    truck, truck with crane ,garbage truck ,vacuum sewage suction truck,etc .
    2.We are supply all brands special truck of SINOTRUK
    3.the drive type could be 4x2 , 4x4 , 6x2 , 6x4 , 6x6 , 8x4
    4.We can provide LHD (left hand drive) or RHD (right hand drive) vehicles.

    5.Factory export department directly sale ,reliable quality
    6.Export experience more than 12 years
    7.Cheap / competitive price, high quality ,you get more than your paid
    8.With CCC, ISO , BV approved
    9.The heart of the service, rational design
