SINOTRUK HOWO 400HP Tipper Dump Truck For Construction A7 Yellow ZZ3257V3847B1

SINOTRUK HOWO 400HP Tipper Dump Truck For Construction A7 Yellow ZZ3257V3847B1

  • SINOTRUK HOWO 400HP Tipper Dump Truck For Construction A7 Yellow ZZ3257V3847B1
  • SINOTRUK HOWO 400HP Tipper Dump Truck For Construction A7 Yellow ZZ3257V3847B1
  • SINOTRUK HOWO 400HP Tipper Dump Truck For Construction A7 Yellow ZZ3257V3847B1
  • SINOTRUK HOWO 400HP Tipper Dump Truck For Construction A7 Yellow ZZ3257V3847B1
SINOTRUK HOWO 400HP Tipper Dump Truck For Construction A7 Yellow ZZ3257V3847B1
Product Details:
Place of Origin: China
Brand Name: SINOTRUK HOWO A7
Certification: ISO/3C/BV/IFA/SGS
Model Number: ZZ3257V3847B1
Payment & Shipping Terms:
Minimum Order Quantity: 1 Unit
Price: USD48000-USD52000/UNIT)negotiation
Packaging Details: Nude or Waxing in Roro or bulk ship
Delivery Time: 25 working days after received your advance payment
Payment Terms: L/C, T/T, Western Union
Supply Ability: 3,000units per month
Contact Now
Detailed Product Description
Product Name: Tipper Dump Truck Model: ZZ3257V3847B1
Drive Type: LHD 6X4 Emission Standard: Euro 2
Engine: WP12.400E201,400 HP( Euro II) Cargo Body: 5800×2300×1500(mm),Bottom:8mm, Side:6mm
Loading Capacity: 30-40tons
High Light:

sinotruk howo 6x4 tipper truck 400HP

,

sinotruk howo 6x4 tipper truck Yellow

,

ZZ3257V3847B1

SINOTRUK HOWO 400HP Tipper Dump Truck for Construction A7 Yellow ZZ3257V3847B1

Description:

The product has reliable structure and high bearing capacity

Load 30-60 tons, power 266HP-420HP, reliable performance, wide range of application.



This model can meet the requirements of severe environment like construction site and

mining area.which can fullfiled  you of short distance transportation of mining rock and

soil as well as engineering construction.





Specifications:





Tipper Dump Truck SINOTRUK HOWO A7 8X4 for Construction ZZ3317N3867N1

Model ZZ3257V3847B1
Drive Type 6X4
Engine

WP12.400E201,400 HP( Euro II)

6 cylinder in-line with water cooling, turbo-charging & inter-cooling,4 stroke electronic fuel injection diesel engine

Displacement : 9.726L

Cabin HW76  cab(with one sleeper, air-conditioner and new-style seat)
Transmission HW19710(10 forwards & 2 reverses)
Front Axle 1×VGD95 ( 9.5 Tons)
Driving Axle HC16, 16Tons
Steering BOSCH hydraulic steering with power assistance.
Clutch Single-plate dry coil-spring clutch, diameter 430mm, hydraulically operating with air assistance
Rim/ Tire 11.00R20,12.00R20,12.00R24 Radial tire
Wheel base 3800+1350(mm)
Overall dimension 8575×2496×3450(mm)
Cargo body 5800×2300×1500(mm),Bottom:8mm, Side:6mm
The curb weight 12200(Kg)
Gross weight 12200(Kg)
Max. speed 75km/h
Color White, red, green, golden and so on.



Applications:



Which is used in Mining industry, Construction business, docks, for transporting soil, sand, stones and so on.



Competitive Advantage:



1) Various types of trucks to meet your needs
2) The world's top technology products are adopted for key components
3) Based on strong technical support and top technology, make the truck higher quality and more reliable

4) Optimized cargo structure, light weight, high rigidity, large load capacity

5) Adopt high strength steel, long service life

6) The optimized sealing structure has better sealing effect.

7) Intelligent hydraulic control system, avoid misoperation, with higher safety and operation efficiency.

8) A variety of box structure and equipment selection

9) Low fuel consumption
10) The engine is strong enough

11) Competitive price, cost-effective
12) Fast and efficient spare parts supply, bring you more convenience
13) Fast delivery time, we can accurately and quickly arrange production according to your needs

14) Professional import and export transaction procedures make customs clearance more efficient
