High Loading Capacity Tipper Dump Truck SINOTRUK HOWO70 Mining Truck 6X4

High Loading Capacity Tipper Dump Truck SINOTRUK HOWO70 Mining Truck 6X4

    • High Loading Capacity Tipper Dump Truck SINOTRUK HOWO70 Mining Truck 6X4
    • High Loading Capacity Tipper Dump Truck SINOTRUK HOWO70 Mining Truck 6X4
    • High Loading Capacity Tipper Dump Truck SINOTRUK HOWO70 Mining Truck 6X4
    • High Loading Capacity Tipper Dump Truck SINOTRUK HOWO70 Mining Truck 6X4
  • High Loading Capacity Tipper Dump Truck SINOTRUK HOWO70 Mining Truck 6X4

    Product Details:

    Place of Origin: China
    Brand Name: SINOTRUK HOWO 70 Mining
    Certification: ISO/3C/BV/IFA/SGS
    Model Number: ZZ5707V3840CJ

    Payment & Shipping Terms:

    Minimum Order Quantity: 1 Unit
    Price: USD78000-USD81000/UNIT)negotiation
    Packaging Details: Nude or Waxing in Roro or bulk ship
    Delivery Time: 25 working days after received your advance payment
    Payment Terms: L/C, T/T, Western Union
    Supply Ability: 2,000units per month
    Detailed Product Description
    Product Name: Tipper Dump Truck Model: ZZ5707V3840CJ
    Drive Type: LHD 6X4 Emission Standard: Euro 2
    Engine: D12.42, 420HP Cargo Body: 5800*3100*1600mm
    Loading Capacity: 70tons

    Tipper Dump Truck SINOTRUK HOWO70 Mining Truck 6X4



    Description:



    Tipper Dump Truck SINOTRUK HOWO70 Mining Truck 6X4 420HP 70tons ZZ5707V3840CJ

    HOWO Mining Dump Truck with unilateral high strength skeleton cab, modelling concise, hale and hearty, broaden their horizons; good sealing can ensure your vehicle is always in the safe and comfortable driving environment; there are each of the two lighting lamps at the top of cabin's front and back for night work.



    The configuration of the HW19710 gearbox, HW70 force, torque up to 700NM.

    Equipped with a 500 liter D type fuel tank (optional 400 liters fuel tank), the workload of vehicle to meet your requirements.

    SINOTRUK independent research and development of new front axle assembly, the application of the whole casting strander beam, 500x210 strengthen type brake for truck parts assembly technology.

    Rear axle adopts AC26 mine driving axle, the main reducer structure design more reasonable, strengthen type casting bridge shell and drum brake the vehicle carrying capacity and braking ability in the leading domestic level.



    Wheel and tyre: 10.0/2-25 wheel assembly, the standard 14.00-25-36PR tire, the original 14.00R25-36PR tire, is specifically for mines overlord customization of high load capacity, high wear-resistant special tires.





    Specification:



    Tipper Dump Truck SINOTRUK HOWO70 Mining Truck 6X4 420HP 70tons ZZ5707V3840CJ

    Model  ZZ5707V3840CJ
    Drive Type 6×4
    Engine

    D12.42 , 420HP( Euro II)

    6 cylinder in-line with water cooling, turbo-charging & inter-cooling,4 stroke electronic fuel injection diesel engine

    Displacement : 11.596L

    Cabin HW7D   unilateral high strength skeleton cab(with one sleeper, air-conditioner and new-style seat)
    Transmission HW19710(10 forwards & 2 reverses)
    Front Axle 1×HF12 ( 12 Tons)
    Driving Axle AC26, 26Tons
    Steering ZF8118 hydraulic steering with power assistance.
    Clutch Single-plate dry coil-spring clutch, diameter 430mm, hydraulically operating with air assistance
    Rim/ Tire 14.00-25,14.00R25,Radial tire
    Wheel base 3800+1500(mm)
    Overall dimension 8700×3300×3670(mm)
    Cargo body

    5800×3100×1600(mm),Bottom:16mm, Side:12mm

    The curb weight 23000(Kg)
    Gross weight 70000 kg
    Max. speed 50km/h
    Color White, red, green, golden and so on.




    Applications:



    HOWO 70 Mining Dump Truck is heavy concentrated engineering design personnel and development, first and foremost applies to all kinds of open pit coal mine, steel mills, hydropower construction, dock, poor road conditions, homework is in bad situations in areas within a short distance transport business development of this car, in terms of the particular user groups, with high economic benefit and social benefit.





    Competitive Advantage:



    1) all kinds of cargo body structure can be designed and produced according to your request, make it have light curb weight , high rigidity , high loading capacity
    2) using the high strength steel, make it has a long service life
    3) The HYVA brand hydraulic control system helps to avoid wrong operation, it has higher

    safety and  running efficiency.
    4) excellant apperance of cabin, safety, reliable
    5) low fuel consumption
    6) strong enough engine
    7) with all kinds of truck model, which can fulfil your requirements
    8) the key parts adopt the world's top technology products
    9) based on strong technical support and top level technology make the trucks with high

    quality and more reliable
    10) competive price, cost-effective
    11) quick and efficient spare parts supply bring you more convenient
    12) fast delivery time, we can arange production according to your needs exactly and

    quickly

    13) professional import and export dealing precedure, make customs clearance more high efficiency
