SINOTRUK WHITE HOWO 371HP Concrete Mixer Truck LHD

SINOTRUK WHITE HOWO 371HP Concrete Mixer Truck LHD

  • SINOTRUK WHITE HOWO 371HP Concrete Mixer Truck LHD
  • SINOTRUK WHITE HOWO 371HP Concrete Mixer Truck LHD
  • SINOTRUK WHITE HOWO 371HP Concrete Mixer Truck LHD
  • SINOTRUK WHITE HOWO 371HP Concrete Mixer Truck LHD
SINOTRUK WHITE HOWO 371HP Concrete Mixer Truck LHD
Product Details:
Place of Origin: China
Brand Name: SINOTRUK
Certification: ISO/3C/BV/IFA/SGS
Model Number: ZZ1257N3841W
Payment & Shipping Terms:
Minimum Order Quantity: 1 Unit
Price: Negotiation
Packaging Details: Waxing in Bulk ship, Roro ship, Container
Delivery Time: 10-30 working days
Payment Terms: L/C, T/T, Western Union
Supply Ability: 3,000 units per month
Contact Now
Detailed Product Description
Model: ZZ1257N3841W Product Name:: Mixer Truck
Engine:: WD615.47 Drive Type: 6×4
Transmission: HW19710(10 Forwards & 2 Reverses) Tank Body Capacity:: 10CBM
High Light:

371 HP Concrete Mixer Truck

,

Concrete Mixer Truck LHD Type

,

SINOTRUK WHITE HOWO 6x4 Truck

SINOTRUK WHITE HOWO 371HP CONCRETE MIXER TRUCK LHD



Description:



he mixing tank consists of highly wear-resistant steel plates and cage molds to ensure the concentricity and roundness of flanges, cylinder components and rolling elements to ensure the normal operation of the vehicle. The main body of the tank adopts double spiral blades with moderate density and conical shape. There is a symmetrical stirring plate at the front gateball. The blades and guide blades are installed in the groove, so the material is used faster.



Specification:



SINOTRUK WHITE  HOWO 371HP Concrete Mixer Truck  LHP
Model ZZ1257N3841W
Drive Type 6×4
Engine
WD615.47 , 371HP( Euro II)
6 cylinder in-line with water cooling, turbo-charging & inter-cooling,4 stroke electronic fuel injection diesel engine
Displacement : 9.726L
Cabin A7-W lengthened cab(with one sleeper, air-conditioner and new-style seat)
Transmission HW19710(10 forwards & 2 reverses)
Front Axle 1×HF9 ( 9 Tons)
Driving Axle HC16, 16Tons
Steering ZF8098 hydraulic steering with power assistance.
Clutch

Single-plate dry coil-spring clutch, diameter 430mm, hydraulically operating with

air assistance

Rim/ Tire 11.00R20,12.00R20,12.00R24 Radial tire
Wheel base 3825+1350(mm)
Overall dimension 8604×2496×3950(mm)
Tank body Capacity 10CBM
The curb weight 12800(Kg)
Gross weight 25000 kg
Max. speed 102km/h
Color White, red, green, golden and so on.




Applications:



It is applicable to infrastructure construction businesses such as mixing and transition concrete, construction site, road repair, etc.



Competitive Advantage:



1) The product has advanced technology, complete functions, excellent performance, reliable quality and convenient operation.



2) The body structure is optimized, the special mold is made, the appearance is beautiful, the concrete is evenly mixed, the discharge is even, and the residual rate is low.



3) Imported hydraulic pump, hydraulic motor and reducer.



4) High strength steel plate is adopted, with long service life.



5) The overall structure is optimized, the center of gravity is low, and the operation efficiency is high.



6) The product range is wide, and the tank capacity is 6-18 cubic meters.



7) Select a variety of auxiliary devices.



8) Match all concrete mixer chassis.



9) Based on strong technical support and top technology, the truck quality is higher and more reliable



10) Competitive price and high cost performance



11) Fast and efficient supply of spare parts brings you more convenience



12) The delivery time is fast. We can arrange production accurately and quickly according to your needs



SINOTRUK WHITE HOWO 371HP Concrete Mixer Truck LHD 0SINOTRUK WHITE HOWO 371HP Concrete Mixer Truck LHD 1
