SINOTRUK Howo Semi Truck Fuel Tank 4x2 Lhd Euro2 290hp White

SINOTRUK Howo Semi Truck Fuel Tank 4x2 Lhd Euro2 290hp White

  • SINOTRUK Howo Semi Truck Fuel Tank 4x2 Lhd Euro2 290hp White
  • SINOTRUK Howo Semi Truck Fuel Tank 4x2 Lhd Euro2 290hp White
  • SINOTRUK Howo Semi Truck Fuel Tank 4x2 Lhd Euro2 290hp White
  • SINOTRUK Howo Semi Truck Fuel Tank 4x2 Lhd Euro2 290hp White
SINOTRUK Howo Semi Truck Fuel Tank 4x2 Lhd Euro2 290hp White
Product Details:
Place of Origin: China
Brand Name: SINOTRUK
Certification: ISO/3C/BV/IFA/SGS
Model Number: ZZ1267N4617B1
Payment & Shipping Terms:
Minimum Order Quantity: 1Unit
Price: Negotiation
Packaging Details: Waxing in Bulk ship, Roro ship, Container
Delivery Time: 10-30 working days
Supply Ability: 3,000 units per month
Contact Now
Detailed Product Description
Product Name: Oil Tank Truck Model: ZZ1267N4617B1
Drive Type: LHD 4x2 Emission Standard: Euro 2
Engine: WD615.87, 290HP Tank Body Capacity: 16-20CBM
High Light:

Fuel Tank Howo Semi Truck

,

Euro2 Oil Tank Truck

,

290HP Howo Semi Truck

SINOTRUK Howo Semi Truck Fuel Tank 4x2 Lhd Euro2 290hp white





Description:



Howo 4x2 tank trucks have a variety of refueling or oil transport functions depending on the application and environment.

It has the functions of oil absorption, oil pump, various oil distribution and oil distribution.

The special part of the tank car is composed of tank body, power output, transmission shaft, gear pump, pipeline, etc

Network system, etc. The pipe network system consists of an oil pump, a three-way four-position ball valve, and a

Two-way ball valves, filters and piping.



Specification:



SINOTRUK HOWO Fuel Tank Truck 6X4 LHD Euro2 290HP

Chassis Model ZZ1267N4617B1
Drive Type 4×2
Engine WD615.87, 290HP
Cabin HW76 lengthened cab(with one sleeper, air-conditioner and two new-style seat)
Transmission HW19710(10 forwards & 2 reverses)
Front Axle HF9(1X9 Tons)
Driving Axle HC16(1X16 Tons)
Clutch hydraulically operating with air assistance
Rim/ Tire 12.00R20, Radial tyre
Wheel base 4600+1350(mm)
Capacity of tank body 16-20CBM
Thickness of tank body 5mm,With 5 cabin
Basic setup Gear oil pump, flow meter, flash hider, fire extinguisher
Overall dimension 9200×2500×3150mm
The curb weight 11940(Kg)
Gross weight 25000 kg
Max. speed 95km/h
Color White, red, green, golden and so on.


Applications:



The Oil tank truck is mainly used for oil derivatives (gasoline, diesel oil, lubricating oil and coal tar oil) transportation and storage.



Competitive Advantage:



1. Through the crash test, driving safety guarantee: steel frame structure, frame safety protection safety four-level safety protection system, through the high standard crash test and can normally leave the test, can withstand two tons of swing arm impact test.



2. Chassis parts with reliable performance of international supporting products.



3. Car interior: humanized interior layout, high-end atmosphere showing taste.



4. The vehicle adopts CAN bus control technology, which improves the reliability and flexibility of the system.


5. The cab is safer, more powerful, more carrying capacity, and more cost-effective than the same model.

SINOTRUK Howo Semi Truck Fuel Tank 4x2 Lhd Euro2 290hp White 0SINOTRUK Howo Semi Truck Fuel Tank 4x2 Lhd Euro2 290hp White 1
