Place of Origin: | China |
Brand Name: | SINOTRUK HOWO A7 |
Certification: | ISO/3C/BV/IFA/SGS |
Model Number: | ZZ4187N3517N1B |
Minimum Order Quantity: | 1 Unit |
---|---|
Price: | USD36000-USD36600/UNIT)negotiation |
Packaging Details: | Nude or Waxing in Roro or bulk ship |
Delivery Time: | 20 working days after received your advance payment |
Payment Terms: | L/C, T/T, Western Union |
Supply Ability: | 4,000units per month |
Product Name: | Tractor Trailer Truck | Model: | ZZ4187N3517N1B |
---|---|---|---|
Feature: | Large Capacity | Front Axle: | 1×HF9 ( 9 Tons) |
Engine: | WD615.69, 336HP | Driving Axle: | HC16, 16Tons |
Traction Capacity: | 30-40tons | ||
High Light: | tractor trailer truck,howo tractor truck |
Euro 2 Tractor Trailer Truck / Large Capacity HOWO Tractor Dump Truck
Tractor Trailer Truck Description:
Tractor Trailer Truck product by the famous Italian design company to help
configuration design, fashion appearance, large and comfortable indoor space. Dynamical
system is strong, the overall optimization of transmission system, fuel economy
performance excellent, AMT make handling more comfort.Front disk brake and back drum
brake type,and also adopts other multi range safety measures, CNHTC developed a new
clutch diaphragm, new front axle is light weight but bearing strong and other advanced
assembly once again stood in the forefront of the domestic high-end heavy truck.
Tractor Trailer Truck Specification:
SINOTRUK HOWO A7 Tractor Truck LHD 4X2 Euro2 336HP ZZ4187N3517N1B | ||||
Model | ZZ4187N3517N1B | |||
Drive Type | 4×2 | |||
Engine |
| |||
Cabin | A7-W(with single sleeper, air-conditioner and new-style seat) | |||
Transmission | HW19712(12 forwards & 2 reverses) | |||
Front Axle | 1×HF9 ( 9 Tons) | |||
Driving Axle | HC16, 16Tons | |||
Steering | ZF8098 hydraulic steering with power assistance. | |||
Clutch | Single-plate dry coil-spring clutch, diameter 430mm, hydraulically operating with air assistance | |||
Rim/ Tire | 12R22.5 tubeless tyre 11.00R20,12.00R20,12.00R24 Radial tire | |||
Wheel base | 3500(mm) | |||
Overall dimension | 6160×2496×3230(mm) | |||
Fifth Wheel | #50, #90 | |||
The curb weight | 6800(Kg) | |||
Gross weight | 18000 kg | |||
Max. speed | 102km/h | |||
Color | White, red, green, golden and so on. |
Tractor Trailer Truck Applications:
Tractor Trailer Truck Is suitable for towing all kinds semi trailer which is used in Logistics business, construction site and
Mining area .
Competitive Advantage:
1) it has higher safety and running efficiency.
2) excellent appearance of cabin, safety, reliable
3) low fuel consumption
4) strong enough engine
Tractor Trailer Truck Detaisl
