Place of Origin: | China |
Brand Name: | SINOTRUK HOWO |
Certification: | ISO/3C/BV/IFA/SGS |
Model Number: | ZZ3317N3867W |
Minimum Order Quantity: | 1 Unit |
---|---|
Price: | USD45000-USD48000/UNIT)negotiation |
Packaging Details: | Nude or Waxing in Roro or bulk ship |
Delivery Time: | 25 working days after received your advance payment |
Payment Terms: | L/C, T/T, Western Union |
Supply Ability: | 3,000units per month |
Product Name: | Tipper Dump Truck | Model: | ZZ3317N3867W |
---|---|---|---|
Drive Type: | LHD 8X4 | Emission Standard: | Euro 2 |
Engine: | WD615.47, 371HP | Cargo Body: | 7800*2300*1500mm |
Loading Capacity: | 40-60tons | Transmission: | HW19710 |
Truck Cabin: | HW76 | Steering: | ZF8098 |
High Light: | heavy dump truck,sinotruk howo dump truck |
SINOTRUK HOWO Dump Truck Orange color 371HP 12 Wheels LHD 60-70tons 20-35CBM
Description:
SINOTRUK HOWO Dump Truck Orange color 371HP 12 Wheels LHD 60-70tons 20-35CBM
This situation with the amount of the tractor based HOWO A7, will be gradually improved. China's marketing department general manager Wang Dechun told reporters, Chinese launched early last year A7 HOWO's original intention, just let the market know this product, and not the pursuit of big sales, because the HOWO series of products is still strong middle period. Chinese heavy truck market mainly rely on selling HOWO products, do not rush to push more high-end HOWO A7. even under such conditions, it has sold nearly 2000 units, with the HOWO A7 truck, cement mixer, mixing car in July will be the national announcement, while HOWO A7 is the flagship product of the towing vehicle. In very fast growth in the market.
China heavy truck sales manager Yu Youde said, HOWO A7 reached 8000 to 10000 should be no problem. In fact, compared to other high-end heavy truck, such as free J6, Dongfeng Denon, A7 from HOWO into the mature period, speed is fast enough.
Specification:
SINOTRUK HOWO Dump Truck Orange color 371HP 12 Wheels LHD 60-70tons 20-35CBM |
||||
Model | ZZ3317N3867W | |||
Drive Type | 8×4 | |||
Engine |
|
|||
Cabin | HW76 lengthened cab(with one sleeper, air-conditioner and new-style seat) | |||
Transmission | HW19710(10 forwards & 2 reverses) | |||
Front Axle | 1×HF9 ( 9 Tons) | |||
Driving Axle | HC16, 16Tons | |||
Steering | ZF8118 hydraulic steering with power assistance. | |||
Clutch |
Single-plate dry coil-spring clutch, diameter 430mm, hydraulically operating with air assistance |
|||
Rim/ Tire | 11.00R20,12.00R20,12.00R24 Radial tire | |||
Wheel base | 1800+3800+1350(mm) | |||
Overall dimension | 10445×2496×3450(mm) | |||
Cargo body |
7800×2300×1500(mm),Bottom:8mm, Side:6mm |
|||
The curb weight | 15120(Kg) | |||
Gross weight | 31000 kg | |||
Max. speed | 75km/h | |||
Color | White, red, green, golden and so on. |
Applications:
It used for Mining industry, Construction business, docks and so on.
Competitive Advantage:
1) Good quality
2) competitive price
3)usually choose the standard cargo body structure
4)using the good quality steel plate, make it has a long service life
5)The optimized hydraulic control system helps to avoid wrong operation, it has higher
safety and running efficiency.
6)excellant apperance of cabin, safety, reliable
7)competive price, cost-effective
8)quick and efficient spare parts supply bring you more convenient
9)fast delivery time, we can arange production according to your needs exactly and
quickly
10) professional import and export dealing precedure, make customs clearance more high efficiency
11) low fuel consumption
12) strong enough engine
13)with all kinds of truck model, which can fulfil your requirements
14)the key parts adopt the world's top technology products
15)based on strong technical support and top level technology make the trucks with high
quality and more reliable
16) good after sales servie
