SINOTRUK HOWO Sewage Suction Truck High Pressure Cleaning 15CBM LHD 290HP

SINOTRUK HOWO Sewage Suction Truck High Pressure Cleaning 15CBM LHD 290HP

  • SINOTRUK HOWO Sewage Suction Truck High Pressure Cleaning 15CBM LHD 290HP
  • SINOTRUK HOWO Sewage Suction Truck High Pressure Cleaning 15CBM LHD 290HP
  • SINOTRUK HOWO Sewage Suction Truck High Pressure Cleaning 15CBM LHD 290HP
  • SINOTRUK HOWO Sewage Suction Truck High Pressure Cleaning 15CBM LHD 290HP
SINOTRUK HOWO Sewage Suction Truck High Pressure Cleaning 15CBM LHD 290HP
Product Details:
Place of Origin: China
Brand Name: SINOTRUK HOWO
Certification: ISO/3C/BV/IFA/SGS
Model Number: ZZ1167N5617B1
Payment & Shipping Terms:
Minimum Order Quantity: 1 Unit
Price: Negotiation
Packaging Details: Nude or Waxing in Roro or bulk ship
Delivery Time: 10-30 working days
Payment Terms: T/T, L/C
Supply Ability: 3,000 units per month
Contact Now
Detailed Product Description
Product Name: Sewage Suction Truck Model: ZZ1167N5617B1
Drive Type: LHD 6X4 Emission Standard: Euro 2
Engine: WD615.87, 290HP Tank Body Capacity: 15-18CBM
High Light:

SINOTRUK HOWO Sewage Suction Truck

,

Euro2 Sewage Suction Truck

,

Sewage Suction Truck 290HP

SINOTRUK HOWO Sewage Suction Truck Vacuum Pump High pressure cleaning 15CBM LHD 290HP​



Description:



Sinotruk HOWO 15CBM LHD 6X4 Euro2 290 HP

German advanced manufacturing technology, the introduction of underground coexistence

Collection and transportation of sewage pipes, sludge, general wastes and buildings

Operation of waste liquid, muddy water and other functions.



Sewage suction truck is a sanitation truck used for collection and transportation.

Municipal sewage sludge, sanitation and large property management

The company has vacuum suction and pressure discharge function to avoid secondary pollution

All efficient and time-saving vacuum pumps and valves are imported.



A variety of brands for you to choose from, such as HOWO, Prince of Gold, HOWO A7, Hohan, Engine

The power is 266HP, 290HP, 336HP, 371HP, etc.

Specification:



SINOTRUK HOWO Sewage Suction Truck Vacuum Pump High pressure cleaning 15CBM LHD 290HP
Chassis Model ZZ1167N5617B1
Drive Type 6×4
Engine WD615.87, 290HP
Cabin HW76 lengthened cab(with one sleeper, air-conditioner and two new-style seat)
Transmission HW15710(10 forwards & 2 reverses)
Front Axle HF9 (1X9Tons)
Driving Axle HC16(2X16Tons)
Clutch hydraulically operating with air assistance
Rim/ Tire 11.00R20
Wheel base 4300+1350(mm)
Capacity of tank body 15-18CBM
Diameter of suction tube Φ100mm
Suction depth ≥ 8 m
Vacuum pump

type: Vane pump

Pumping speed: 318 m3/h

Rated speed: 1300rpm

Overall dimension 9400×2500×3850mm
The curb weight 12050(Kg)
Gross weight 25000 kg
Max. speed 95km/h
Color White, red, green, golden and so on.


Applications:



It can be widely used in urban rainwater collection well, inspection well and all kinds of ditches

Suction, shipment and discharge of sediment from sludge, sewage or petrochemical sewage ponds.



Competitive Advantage:



1) Including chassis, power take-off, drive shaft, vacuum suction pump, pressure

Water tank, hydraulic components, piping system, vacuum pressure gauge, waste component window,

Cleaning device, vehicle equipped with high power vacuum suction pump and mass

In the hydraulic system, once the tank head is pressed, the back door of the tank can be opened and dumped

It consists of two cylinders.
2) The trucks produced by our company have the function of hydraulic door opening

The opening Angle of the system is 60 degrees. Hand wheel lock or automatic lock is optional

Hydraulic lock. Special seal, high reliable sealing. Arrangement of

The vacuum pump is flexible and optimized according to the vacuum pipeline

When installed, it is also brought for hydraulic actuated automatic control system Convenient.
3) Optimized hydraulic control system, avoid misoperation, with higher performance Safe and efficient operation.
4) The cabin has good appearance, safety and reliability
5) Low fuel consumption
6) Various types of trucks to meet your needs
7) World top technology products are adopted for key components
8) Based on strong technical support and top technology to make the truck with high More reliable quality
9) Competitive price, cost-effective
10) Fast and efficient spare parts supply, to bring you more convenient
11) Fast delivery time, we can accurately and accurately arrange production according to your needs soon
12) Professional import and export transaction procedures, so that customs clearance is higher efficiency
