High Efficiency Oil Tank Truck 8X4 LHD Euro2 400HP 31000KG

High Efficiency Oil Tank Truck 8X4 LHD Euro2 400HP 31000KG

  • High Efficiency Oil Tank Truck 8X4 LHD Euro2 400HP 31000KG
  • High Efficiency Oil Tank Truck 8X4 LHD Euro2 400HP 31000KG
  • High Efficiency Oil Tank Truck 8X4 LHD Euro2 400HP 31000KG
  • High Efficiency Oil Tank Truck 8X4 LHD Euro2 400HP 31000KG
High Efficiency Oil Tank Truck 8X4 LHD Euro2 400HP 31000KG
Product Details:
Place of Origin: China
Brand Name: SINOTRUK
Certification: ISO/3C/BV/IFA/SGS
Model Number: ZZ1317V4667B1
Payment & Shipping Terms:
Minimum Order Quantity: 1 Unit
Price: Negotiation
Packaging Details: Nude or Waxing in Roro or bulk ship
Delivery Time: 25 working days after received your advance payment
Payment Terms: L/C, T/T
Supply Ability: 3,000 units per month
Contact Now
Detailed Product Description
Product Name: Oil Tank Truck Model: ZZ1317V4667B1
Drive Type: LHD 8X4 Emission Standard: Euro 2
Engine: WP12.400E201, Euro2, 400HP, Tank Body Capacity: 30CBM
High Light:

Oil Tank Truck High Efficiency

,

8X4 LHD Oil Tank Truck

,

400HP Oil Tanker Trailer

High Efficiency Oil Tank Truck 8X4 LHD Euro2 400HP 31000KG



Oil Tank Truck SINOTRUK 30CBM for Oil Transportation 8X4 LHD Euro2 400HP



Description:



Sinotruk 25 - 30cbm tank truck 8x4 LHD euro2 400hp
Oil tank trucks are also called mobile oil tank trucks, computer tank trucks, oil tank trucks, oil tank trucks, oil tractors, oil product transport vehicles, and edible oil transport vehicles. They are mainly used for petroleum derivatives (gasoline, diesel, lubricating oil and coal) and storage of asphalt). According to various gases or oils, and different use environments, oil distribution, oil pumps, various oil equipment, and discharge functions. The special part of the tank truck is composed of fuel tank, power collector, transmission shaft, gear pump and pipeline system. The pipeline system is composed of oil pump, four-way three-way ball valve and two-way valve. filter tube.
The tank car produced by our company adopts advanced butt welding technology,
After the high-pressure gas is formed, it is used for the leak test of the tank body, and the tank body has a high
High strength, stable center of gravity, safe and stable driving; the tank body is welded after firing
Sand blasting pre-treatment process, anti-rust, using advanced paint technology to paint, durable
nice look. Separate silos, different oil seeds,
Chemical, food, liquid food truck, chemical liquid truck and liquid isolation
Use transport trucks, hazmat trucks, asphalt trucks.



Specification:



Oil Tank Truck SINOTRUK 30CBM for Oil Transportation 8X4 LHD Euro2 400HP
Chassis Model ZZ1317V4667B1
Drive Type 8×4
Engine WP12.400E201, Euro2, 400HP,
Cabin L2000 lengthened cab(with one sleeper, air-conditioner and two new-style seat)
Transmission HW15710(10 forwards & 2 reverses)
Front Axle HF9(1X9 Tons)
Driving Axle HC16(1X16 Tons)
Clutch hydraulically operating with air assistance
Rim/ Tire 11.00R20, Radial tyre
Wheel base 1800+4600+1350(mm)
Capacity of tank body 25-30CBM
Thickness of tank body 5mm,With 6cabin
Basic setup Gear oil pump, flow meter, flash hider, fire extinguisher
Overall dimension 11894×2500×3550mm
FAW 14000 Kg
GCW/GVW 31000 kg
Max. speed 95km/h
Color White, red, green, golden and so on.


Applications:



The Oil tank truck is mainly used for oil derivatives (gasoline, diesel oil, lubricating oil and coal tar oil)

transportation and storage.



Competitive Advantage:



1) Our company produces the Oil tank truck with advanced butt welding technology, after the forming

of the tank high pressure gas leak detection, the tank has a high intensity, stable center of gravity,

safe and stable vehicle characteristics;

2) Shot blasting pre treatment process after welding tank, rust, paint adopts the advanced baking technology, durable and beautiful appearance. Independent sub positions,

3) Divided into different oil products, chemicals, food, as liquid food truck, chemical liquid truck,

insulation liquid vehicles, dangerous goods transport vehicles, the asphalt transportation vehicle

4) External sandblasting processing of tank, internal anti-corrosion treatment, Outside surface adopts advanced polyurethane paint, beautiful appearance

5) Front and back high spray is optional, water jet diffusion function, 360 degrees of rotation,

150 degree tilt up and down. Options small flow pump, spraying reel to wake insecticidal garden trees

flowers and plants

6) with all kinds of truck model, which can fulfill your requirement
7) the key parts adopt the world's top technology products
8) based on strong technical support and top level technology make the trucks with high quality and

more reliable
9) competitive price, cost-effective
10) quick and efficient spare parts supply bring you more convenient

11) fast delivery time, we can arrange production according to your needs exactly and quickly

12) professional import and export dealing procedure, make customs clearance more high efficiency
