NEW HOWO HOHAN SINOTRUK Concrete Mixer Truck Black 10CBM 380HP 8X4 RHD

NEW HOWO HOHAN SINOTRUK Concrete Mixer Truck Black 10CBM 380HP 8X4 RHD

  • NEW HOWO HOHAN SINOTRUK Concrete Mixer Truck Black 10CBM 380HP 8X4 RHD
  • NEW HOWO HOHAN SINOTRUK Concrete Mixer Truck Black 10CBM 380HP 8X4 RHD
  • NEW HOWO HOHAN SINOTRUK Concrete Mixer Truck Black 10CBM 380HP 8X4 RHD
  • NEW HOWO HOHAN SINOTRUK Concrete Mixer Truck Black 10CBM 380HP 8X4 RHD
NEW HOWO HOHAN SINOTRUK Concrete Mixer Truck Black 10CBM 380HP 8X4 RHD
Product Details:
Place of Origin: China
Brand Name: SINOTRUK HOWO
Certification: ISO/3C/BV/IFA/SGS
Model Number: ZZ1317V326JB1R
Payment & Shipping Terms:
Minimum Order Quantity: 1 Unit
Price: negotiation
Packaging Details: Nude or Waxing in Roro or bulk ship
Delivery Time: 25 working days after received your advance payment
Payment Terms: L/C, T/T, Western Union
Supply Ability: 2,000units per month
Contact Now
Detailed Product Description
Product Name:: Concrete Mixer Truck Model:: ZZ1317V326JB1R
Emission Standard:: Standard: Euro 2 Engine:: D12.38-40 380HP
Tank Body Capacity:: 10CBM Drive Type:: RHD 8X4
Highlight:

10CBM Concrete Mixer Truck

,

Black Concrete Mixer Truck

,

8X4 Concrete Mixer Truck

NEW HOWO HOHAN SINOTRUK Concrete Mixer Truck Black 10CBM 380HP 8X4 RHD



Description:



HOWO SINOTRUK Concrete Mixer Truck High Efficiency 12CBM 400HP 8X4 RHD

The HOWO concrete mixer truck adopts a HOWO chassis, equipped with an H77L single berth cabin, specifically designed for export, equipped with Euro 3 or electronic common rail, EU. The engine independently developed by China National Heavy Duty Truck, imported from Germany with ZF steering, HOWO 10 and 12 gearbox, HF9 ton front axle, HC16 or AC16 rear axle, has a large load-bearing capacity to meet customer needs. The mixing tank body is made of high-strength wear-resistant steel plates, and the cage mold is integrally formed to ensure the coaxiality and lap of the flange, cross-sectional cylinder body, and rolling, ensuring the smooth operation of the vehicle. The tank body adopts double spiral blades, with moderate density and front taper. The symmetrical mixing plate and groove of the gate ball are equipped with blades and Material guide vanes allow for faster access to materials.





Specification:



 HOWO SINOTRUK Concrete Mixer Truck White 10CBM 380HP 8X4 RHD
Model ZZ1317V326JB1R
Drive Type 8×4
Engine
D12.38-40 380HP( Euro III)
In-line, water-cooled, four-stroke, supercharged and intercooled
Displacement :11.596L
Cabin H77L
Transmission HW19710(10 forwards & 2 reverses)
Front Axle 1×HF9 ( 9 Tons)
Driving Axle HC16, 16Tons
Steering ZF8098 hydraulic steering with power assistance.
Clutch

Single-plate dry coil-spring clutch, diameter 430mm, hydraulically operating with

air assistance

Rim/ Tire 11.00R20,12.00R20,12.00R24 Radial tire
Wheel base 3225+1350(mm)
Overall dimension 8204×2496×3850(mm)
Tank body Capacity 10CBM
The curb weight 19000(Kg)
Gross weight 51000kg
Max. speed 102km/h
Color White, red, green, golden and so on.






Applications:



t’s suitable for agitating and transiting concrete, for construction site, road repairing and some other infrastructure construction business.



Competitive Advantage:



1) Leading technology, complete functions, excellent performance, reliable quality, easy to operate Operation.

2) Optimization of body structure, special mold production, beautiful appearance, concrete mixing,

Uniform discharge and low residual rate.

3) Imported hydraulic pump, hydraulic motor, reducer.

4) Adopt high strength steel plate, long service life.

5) Overall structure optimization, low center of gravity, high operation efficiency.

6) Wide range of products, tank capacity of 6 ~ 18 cubic meters.

7) Choose a variety of auxiliary devices.

8) Match all concrete mixer chassis.

9) Based on strong technical support and top technology to make the truck with high

More reliable quality
10) Competitive price, cost-effective
11) Fast and efficient spare parts supply, to bring you more convenient
12) Fast delivery time, we can accurately and reasonably arrange production according to your needs soon

13) Professional import and export transaction procedures make customs clearance more efficient



NEW HOWO HOHAN SINOTRUK Concrete Mixer Truck Black 10CBM 380HP 8X4 RHD 0
