Place of Origin: | China |
Brand Name: | SINOTRUK |
Certification: | ISO/3C/BV/IFA/SGS |
Model Number: | ZZ1257N3847W |
Minimum Order Quantity: | 1 Unit |
---|---|
Price: | negotiation |
Packaging Details: | Nude or Waxing in Roro or bulk ship |
Delivery Time: | 25 working days after received your advance payment |
Payment Terms: | T/T, L/C |
Supply Ability: | 3,000units per month |
Drive Type: | Concrete Mixer Truck | Emission Standard: | Euro2 |
---|---|---|---|
Engine: | WP12.400E201 400HP Euro 2 | Loading Capacity:: | 6-12CBM |
Steering: | BOSCH Or China Brand | Highlight: | Concrete Mixer Truck 400HP, High Horsepower HOWO Mixer Truck, 10 Wheels HOWO Mixer Truck |
Highlight: | 6-12CBM Mixer Truck,10 Wheels Mixer Truck,400HP Mixer Truck |
LHD 6×4 10wheels High Horsepower 400HP Concrete Mixer Truck
Sinotruk Howo Concrete Mixer Truck 6-12CBM 6 x 4 Euro 400Hp Construction
Description:
HOWO mixer, suitable for urban construction, highway, railway and other departments. Stirring truck is one of the indispensable important equipment in mechanized construction. The body material is made of special wear-resistant alloy material. The concrete mixing transport uniformity is good. Loading and discharging
Fast speed, low slag discharge rate, reliable hydraulic system, easy to operate, beautiful appearance.
Specification:
Sinotruk Howo Concrete Mixer Truck 6-12CBM 6 x 4 Euro 2 340Hp Construction | ||||
Model | ZZ1257N3847B1 | |||
Drive Type | 6×4 | |||
Engine |
|
|||
Cabin | HW76 lengthened cab(with one sleeper, air-conditioner and new-style seat) | |||
Transmission | HW19710(10 forwards & 2 reverses) | |||
Front Axle | 1×VGD95 ( 9.5 Tons) | |||
Driving Axle | 2×HC16, 2×16Tons | |||
Steering | BOSCH or China brand hydraulic steering with power assistance. | |||
Clutch |
Single-plate dry coil-spring clutch, diameter 430mm, hydraulically operating with air assistance |
|||
Rim/ Tire | 11.00R20,12.00R20,12.00R24 Radial tire | |||
Wheel base | 3800+1350(mm) | |||
Overall dimension | 8075×2600×3000(mm) | |||
Tank body Capacity | 6-12CBM | |||
The curb weight | 12650(Kg) | |||
Gross weight | 31000 kg | |||
Max. speed | 102km/h | |||
Color | White, red, green, golden and so on. |
Applications:
t’s suitable for agitating and transiting concrete, for construction site, road repairing and some other
infrastructure construction business.
Competitive Advantage:
1) Leading product technology, complete functions, excellent performance, reliable quality, easy to operate.
2) Valve body structure optimization, special mold production, beautiful appearance, uniform concrete mixing, uniform discharge, low residual rate.
3) Imported hydraulic pump, hydraulic motor, reducer.
4) The interior of the mixer adopts the mode of large blade and multi-phase three-dimensional mixing, which is more in line with the characteristics of Chinese concrete, and the speed of entering and leaving the material is fast and the residual rate is lower
5) Overall structure optimization, low center of gravity, high operating efficiency.
6) Wide product range, tank capacity 6 ~ 18 cubic meters.
7) Choose a variety of auxiliary devices.
8)The tank material is made of the latest generation of special high-strength wear-resistant steel for mixing trucks, and the blades are also equipped with wear-resistant strips, so the service life is longer than that of ordinary tanks
9) Relying on strong technical support and first-class technology, make the truck with high quality and more reliable
10) The price is competitive and cost-effective
11) Fast and efficient spare parts supply to bring you more convenience
12) Delivery time is fast, we can precisely arrange production according to your needs quickly
13) Professional import and export transaction process, making customs clearance more efficient
