Compact Structure Tractor Trailer Truck 6X4 Euro2 290HP ZZ4251M3241W

Compact Structure Tractor Trailer Truck 6X4 Euro2 290HP ZZ4251M3241W

    • Compact Structure Tractor Trailer Truck 6X4 Euro2 290HP ZZ4251M3241W
    • Compact Structure Tractor Trailer Truck 6X4 Euro2 290HP ZZ4251M3241W
    • Compact Structure Tractor Trailer Truck 6X4 Euro2 290HP ZZ4251M3241W
    • Compact Structure Tractor Trailer Truck 6X4 Euro2 290HP ZZ4251M3241W
  • Compact Structure Tractor Trailer Truck 6X4 Euro2 290HP ZZ4251M3241W

    Product Details:

    Place of Origin: China
    Brand Name: SINOTRUK Golden Prince
    Certification: ISO/3C/BV/IFA/SGS
    Model Number: ZZ4251M3241W

    Payment & Shipping Terms:

    Minimum Order Quantity: 1 Unit
    Price: USD33600-USD35000/UNIT)negotiation
    Packaging Details: Nude or Waxing in Roro or bulk ship
    Delivery Time: 20 working days after received your advance payment
    Payment Terms: L/C, T/T, Western Union
    Supply Ability: 4,000units per month
    Contact Now
    Detailed Product Description
    Product Name: Tractor Truck Model: ZZ4251M3241W
    Drive Type: RHD 6X4 Emission Standard: Euro 2
    Engine: WD615.87, 290HP Fifth Wheel: #50, #90
    Traction Capacity: 60-70tons

    Tractor Truck SINOTRUK Golden Prince RHD 6X4 Euro2 290HP ZZ4251M3241W



    Description:



    Tractor Truck SINOTRUK Golden Prince RHD 6X4 Euro2 290HP ZZ4251M3241W

    Golden Prince Tractor truck adopts the MAN technology L2000 Cab,with advantages of

    compact structure,decent line spaciously comfortable,wide view , big open angle of door,

    big angle of cab tilt and easy for maintenance. It is equipped with SINOTRUK engine,

    SINOTRUK HW series gear box, single or double reduction driving axles, it has the feature

    of light self weight, strong carrying capacity, strong power, high reliability, strong

    grade ability and high economic vehicle speed,etc.



    Gold Prince Tractor Truck, divide into two editions: highway version and the 5 version of

    the integrated operating conditions. In accordance with the drive form is divided into

    6X4 and 4X2,6X2 models.Edition 5 6X4 models, the standard double deck frame; four U-

    bolts; #90 saddle; 10 gear box (according to the conditions of the road can choose

    different torque changing power output), the HC16 double rear axle rear axle(according to

    the actual conditions to select the appropriate speed ratio); the front axle of HF9 or

    HF7 (9 tons or 7 tons of front axle, drum and disc brake type), the engine from 266HP to

    336HP (maximum horsepower is 336HP, emission standard can choose Euro2 and Euro3),

    Steering is D50 model (optional ZF steering); 12R22.5 tubeless tyres (can according to

    customer needs selection of domestic and imported tire brand).



    Specification:



    Tractor Truck SINOTRUK Golden Prince RHD 6X4 Euro2 290HP ZZ4251M3241W

    Model ZZ4251M3241W
    Drive Type 6×4
    Engine

    WD615.87 , 290HP( Euro II)

    6 cylinder in-line with water cooling, turbo-charging & inter-cooling,4 stroke electronic fuel injection diesel engine

    Displacement : 9.726L

    Cabin L2000  medium length cab(with one sleeper, air-conditioner and new-style seat)
    Transmission HW15710(10 forwards & 2 reverses)
    Front Axle 1×HF9 ( 9 Tons)
    Driving Axle HC16, 16Tons
    Steering D50 hydraulic steering with power assistance.
    Clutch

    Single-plate dry coil-spring clutch, diameter 430mm, hydraulically operating with

    air assistance

    Rim/ Tire

    12R22.5 tubeless tyre

    11.00R20,12.00R20,12.00R24 Radial tire
    Wheel base 3200(mm)
    Overall dimension

    6520×2490×3070(mm)

    Fifth Wheel

    #50, #90

    The curb weight 8500(Kg)
    Gross weight 25000 kg
    Max. speed 90km/h
    Color White, red, green, golden and so on.




    Applications:



    It’s suitable for towing all kinds semi trailer which is used in Logistics business, construction site and

    Mining area .



    Competitive Advantage:



    1) it has higher safety and  running efficiency.

    2) excellent appearance of cabin, safety, reliable

    3) low fuel consumption

    4) strong enough engine

    5) with all kinds of truck model, which can fulfill your requirement

    6) the key parts adopt the world's top technology products

    7) based on strong technical support and top level technology make the trucks with high quality and more

    reliable

    8) competitive price, cost-effective

    9) quick and efficient spare parts supply bring you more convenient

    10) fast delivery time, we can arrange production according to your needs exactly and Quickly

    11) professional import and export dealing procedure, make customs clearance more high efficiency
