Compact Garbage Collection Truck 6cbm For Non - Toxic Waste Transportation

Compact Garbage Collection Truck 6cbm For Non - Toxic Waste Transportation

    • Compact Garbage Collection Truck 6cbm For Non - Toxic Waste Transportation
    • Compact Garbage Collection Truck 6cbm For Non - Toxic Waste Transportation
    • Compact Garbage Collection Truck 6cbm For Non - Toxic Waste Transportation
    • Compact Garbage Collection Truck 6cbm For Non - Toxic Waste Transportation
  • Compact Garbage Collection Truck 6cbm For Non - Toxic Waste Transportation

    Product Details:

    Place of Origin: China
    Brand Name: SINOTRUK HOWO
    Certification: ISO/3C/BV/IFA/SGS
    Model Number: ZZ1087D3415C180

    Payment & Shipping Terms:

    Minimum Order Quantity: 1 Unit
    Price: USD28000-USD29000/UNIT)negotiation
    Packaging Details: Nude or Waxing in Roro or bulk ship
    Delivery Time: 25 working days after received your advance payment
    Payment Terms: L/C, T/T, Western Union
    Supply Ability: 2,000units per month
    Contact Now
    Detailed Product Description
    Product Name: Compressed Garbage Collection Truck Model: ZZ1087D3415C180
    Drive Type: LHD 4X2 Emission Standard: Euro 2
    Engine: CY4102, 110HP Tank Body Capacity: 5-6CBM

    Compressed Garbage Collection Truck SINOTRUK HOWO 6CBM LHD 4X2 ZZ1087D3415C180



    Description:



    Compressed Garbage Collection Truck SINOTRUK HOWO 6CBM LHD 4X2 ZZ1087D3415C180

    Compressed garbage truck, connecting the main compartment with a collection box, with the

    most reasonable angle, blade type main launch board, has a special parabolic surface

    optimal loading angle formed by compressed garbage collecting box filling mechanism of

    30T above the rolling force, with 10T loading pressure in the pressure compartment, at

    the same time, launched in 5T has always been to squeeze pressure, squeeze compressed

    garbage, is conducive to the compressed garbage from the main carriage. Full volume

    utilization rate can reach more than 97%.



    The vehicle function is complete, easy to operate, garbage loading, the hydraulic drive

    and electronic program controller control, accurate, reliable performance, performance

    and reliable. The garbage filling body, can automatically continuous work, can also be

    semi automatic one-way work, or manual operation, and return to the function.



    The vehicle hydraulic drive, the maximum working pressure of 210bar, the system working

    pressure 180bar, rolling force on a garbage collection box is 30 tons, by collecting box

    into the main chamber when the loading capacity is 10 tons, the main launch plate on the

    extrusion pressure of compressed garbage, keeping 5 tons of garbage unloading force

    launched the 10 tons, the compression loading mechanism of each loading compression cycle

    time is 25 seconds, the launch cycle time in shirk refuse, no more than 45 seconds.





    Specification:



    Compressed Garbage Collection Truck SINOTRUK HOWO 6CBM LHD 4X2 ZZ1087D3415C180

    Chassis Model

    ZZ1087D3415C180

    Drive Type

    4×2

    Engine

    CY4102, 83KW/110HP

    Cabin

    2080 lengthened cab(with one sleeper, air-conditioner and two new-style seat)

    Transmission

    HW35505TCL(5 forwards & 1 reverses)

    Front Axle

    2.7 Tons

    Driving Axle

    5.5Tons

    Clutch

    hydraulically operating with air assistance

    Rim/ Tire

    7.50-16LT,7.50R16LT

    Wheel base

    3360(mm)

    Capacity of Cargo body

    5-6CBM

    Time of cycle

    ≦25s

    Time of discharge

    ≦40s

    Max compression

    ≧35000kgs

    Overall dimension

    6520×2050×2460(mm)

    The curb weight

    3950(Kg)

    Gross weight

    8000 kg

    Max. speed

    95km/h

    Color

    White, red, green, golden and so on.


    Applications:



    Which is mainly used for municipal solid waste (MSW), commercial waste, and are used for non-toxic, non

    corrosive and non industrial radioactive waste collection and transportation.



    Competitive Advantage:



    1) The vehicle function is complete, easy to operate, big garbage loading capacity

    2) the hydraulic drive and electronic program controller control is more accurate and with reliable performance

    3) The optimized hydraulic control system helps to avoid wrong operation, it has higher safety and running

    efficiency.

    4) excellent appearance of cabin, safety, reliable
    5) low fuel consumption
    6) with all kinds of truck model, which can fulfill your requirement
    7) the key parts adopt the world's top technology products
    8) based on strong technical support and top level technology make the trucks with high quality and more

    reliable
    9) competitive price, cost-effective
    10) quick and efficient spare parts supply bring you more convenient

    11) fast delivery time, we can arrange production according to your needs exactly and quickly

    12) professional import and export dealing procedure, make customs clearance more high efficiency
