6500 Gallon Water Truck Water Tank Truck Hydraulically Operating Air Assistance

6500 Gallon Water Truck Water Tank Truck Hydraulically Operating Air Assistance

    • 6500 Gallon Water Truck Water Tank Truck Hydraulically Operating Air Assistance
    • 6500 Gallon Water Truck Water Tank Truck Hydraulically Operating Air Assistance
    • 6500 Gallon Water Truck Water Tank Truck Hydraulically Operating Air Assistance
    • 6500 Gallon Water Truck Water Tank Truck Hydraulically Operating Air Assistance
  • 6500 Gallon Water Truck Water Tank Truck Hydraulically Operating Air Assistance

    Product Details:

    Place of Origin: China
    Brand Name: SINOTRUK HOWO
    Certification: ISO/3C/BV/IFA/SGS
    Model Number: ZZ1317N4641W

    Payment & Shipping Terms:

    Minimum Order Quantity: 1 Unit
    Price: USD41000-USD41500/UNIT)negotiation
    Packaging Details: Nude or Waxing in Roro or bulk ship
    Delivery Time: 25 working days after received your advance payment
    Payment Terms: L/C, T/T, Western Union
    Supply Ability: 2,000units per month
    Contact Now
    Detailed Product Description
    Product Name: Water Tank Truck Model: ZZ1317N4641W
    Drive Type: LHD 8X4 Emission Standard: Euro 2
    Engine: WD615.69, 336HP Tank Body Capacity: 25-35CBM

    SINOTRUK Water tank truck 25-35CBM for water carrying 8X4, 336HP, LHD



    Description:



    SINOTRUK Water tank truck 25-35CBM for water carrying 8X4, 336HP, LHD

    Which can choose more truck chassis brand, such as HOWO, HOWO A7, Golden prince, STYER and so on. SINOTRUK Water tank truck is widely used in city landscaping, road or ming site dusty restrain.



    Working principle is truck engine driven gearbox, gearbox mounted power take-off drive

    sprinkler pumps, sprinkler pump produces the main driving force, inside the tank of

    liquid through the pipe to spray out.



    Self suction height: less than or equal to 7m, sprinkler width: is equal to or more than 20m, maximum range: greater than or equal to 28m; adjusting the pillars, the range is more than or equal to 28m; also can be adjusted into a mist, a range of equal to or more than 5m.



    Before the spray sprinkle, is arranged

    in front of the duck shaped nozzle or round blunt mouth, mounted behind the open sprinkler nozzle or shower nozzle of cylinder, at the back of the work platform, equipped with water cannons.





    Specification:



    SINOTRUK Water tank truck 25-35CBM for water carrying 8X4, 336HP, LHD

    Chassis Model

    ZZ1317N4641W

    Drive Type

    8×4

    Engine

    WD615.69, 336HP

    Cabin

    HW76 lengthened cab(with one sleeper, air-conditioner and two new-style seat)

    Transmission

    HW15710(10 forwards & 2 reverses)

    Front Axle

    HF9(1X9 Tons)

    Driving Axle

    HC16(1X16 Tons)

    Clutch

    hydraulically operating with air assistance

    Rim/ Tire

    11.00R20, Radial tyre

    Wheel base

    1800+4325+1350(mm)

    Capacity of tank body

    25-35CBM

    Spraying width of travel

    14.8m

    Spraying height

    ≧30m

    Water sucking depth

    ≧4m

    Overall dimension

    11920×2496×3550mm

    The curb weight

    15180(Kg)

    Gross weight

    31000 kg

    Max. speed

    95km/h

    Color

    White, red, green, golden and so on.


    Applications:



    The Water tank truck is mainly used for construction of mines and other enterprises, road flushing and

    dust covering in large-medium-scale cities.



    Competitive Advantage:



    1) fast delivery time, we can arrange production according to your needs exactly and quickly

    2) professional import and export dealing procedure, make customs clearance more high efficiency

    3) High pressure, wide range of spraying good flushing effect

    4) Blunt head universal adjustment, meet the arbitrary Angle and the combination of the flush operation

    5) Pneumatic control and manual control system can realize two functions

    6) Front and back high spray is optional, water jet diffusion function, 360 degrees of rotation,

    150 degree tilt up and down. Options small flow pump, spraying reel to wake insecticidal garden trees

    flowers and plants

    7) External sandblasting processing of tank, internal anti-corrosion treatment, Outside surface adopts advanced polyurethane paint, beautiful appearance

    8) with all kinds of truck model, which can fulfill your requirement
    9) the key parts adopt the world's top technology products
    10) based on strong technical support and top level technology make the trucks with high quality and

    more reliable

    11) competitive price, cost-effective
    12) quick and efficient spare parts supply bring you more convenient





    6500 Gallon Water Truck Water Tank Truck Hydraulically Operating Air Assistance6500 Gallon Water Truck Water Tank Truck Hydraulically Operating Air Assistance
