Oil Transport Vehicle Fuel Oil Delivery Truck Mobile Station 25 - 30 CBM Euro 2

Oil Transport Vehicle Fuel Oil Delivery Truck Mobile Station 25 - 30 CBM Euro 2

  • Oil Transport Vehicle Fuel Oil Delivery Truck  Mobile Station 25 - 30 CBM Euro 2
  • Oil Transport Vehicle Fuel Oil Delivery Truck  Mobile Station 25 - 30 CBM Euro 2
  • Oil Transport Vehicle Fuel Oil Delivery Truck  Mobile Station 25 - 30 CBM Euro 2
  • Oil Transport Vehicle Fuel Oil Delivery Truck  Mobile Station 25 - 30 CBM Euro 2
Oil Transport Vehicle Fuel Oil Delivery Truck  Mobile Station 25 - 30 CBM Euro 2
Product Details:
Place of Origin: China
Brand Name: SINOTRUK HOWO
Certification: ISO/3C/BV/IFA/SGS
Model Number: ZZ1317N4667W
Payment & Shipping Terms:
Minimum Order Quantity: 1 Unit
Price: USD46000-USD46500/UNIT)negotiation
Packaging Details: Nude or Waxing in Roro or bulk ship
Delivery Time: 25 working days after received your advance payment
Payment Terms: L/C, T/T, Western Union
Supply Ability: 2,000units per month
Contact Now
Detailed Product Description
Product Name: Oil Tank Truck Model: ZZ1317N4667W
Drive Type: LHD 8X4 Emission Standard: Euro 2
Engine: WD615.69, 336HP Tank Body Capacity: 25-30CBM
High Light:

fuel tanker truck

,

gasoline tanker trucks

Oil Transport Vehicle Oil Tank Truck Mobile Station , Fuel Oil Trucks 25-30CBM



Description:



Oil Transport Vehicle Oil Tank Truck Mobile Station , Fuel Oil Trucks 25-30CBM

The tanker is also called mobile fuel trucks, computer refueling vehicle, oil tanker, tanker loading oil,  pulling oil, oil truck, edible oil transport vehicle, mainly for oil derivatives (gasoline, diesel oil, lubricating  oil and coal tar oil) transportation and storage. According to a variety of gas or oil, and the use of  different environment with the oil, pump oil, a variety of oil equipment, put the function. Tanker special  part is composed of a tank, PTO, drive shaft, gear pump, pipeline system components. Pipes system is  composed of an oil pump, three through four ball valve, two-way valve. Filter pipe.



Divided into different oil products, chemicals, food, as liquid food truck, chemical liquid truck,

insulation liquid vehicles, dangerous goods transport vehicles, the asphalt transportation vehicle



Specification:



Oil Transport Vehicle Oil Tank Truck Mobile Station , Fuel Oil Trucks 25-30CBM

Chassis Model

ZZ1317N4667W

Drive Type

8×4

Engine

WD615.69, 336HP

Cabin

HW76 lengthened cab(with one sleeper, air-conditioner and two new-style seat)

Transmission

HW15710(10 forwards & 2 reverses)

Front Axle

HF9(1X9 Tons)

Driving Axle

HC16(1X16 Tons)

Clutch

hydraulically operating with air assistance

Rim/ Tire

11.00R20, Radial tyre

Wheel base

1800+4600+1350(mm)

Capacity of tank body

25-30CBM

Thickness of tank body

5mm,With 6cabin

Basic setup

Gear oil pump, flow meter, flash hider, fire extinguisher

Overall dimension

11894×2500×3550mm

The curb weight

12300(Kg)

Gross weight

31000 kg

Max. speed

95km/h

Color

White, red, green, golden and so on.


Applications:



The Oil tank truck is mainly used for oil derivatives (gasoline, diesel oil, lubricating oil and coal tar oil)

transportation and storage.



Competitive Advantage:



1) Our company produces the Oil tank truck with advanced butt welding technology, after the forming of  the tank high pressure gas leak detection, the tank has a high intensity, stable center of gravity, safe  and stable vehicle characteristics;

2) Shot blasting pre treatment process after welding tank, rust, paint adopts the advanced baking  technology, durable and beautiful appearance. Independent sub positions,

3) External sandblasting processing of tank, internal anti-corrosion treatment,        Outside surface adopts advanced polyurethane paint, beautiful appearance

4) Front and back high spray is optional, water jet diffusion function, 360 degrees of rotation,

150 degree tilt up and down. Options small flow pump, spraying reel to wake insecticidal garden trees

flowers and  plants

5) with all kinds of truck model, which can fulfill your requirement
6) the key parts adopt the world's top technology products
7) based on strong technical support and top level technology make the trucks with high quality and

more reliable
8) competitive price, cost-effective
9) quick and efficient spare parts supply bring you more convenient

10) fast delivery time, we can arrange production according to your needs exactly and quickly

11) professional import and export dealing procedure, make customs clearance more high efficiency
