SINOTRUK Container Side Loader Working With HOWO 8X4 Cargo Truck Chassis

SINOTRUK Container Side Loader Working With HOWO 8X4 Cargo Truck Chassis

    • SINOTRUK Container Side Loader Working With HOWO 8X4 Cargo Truck Chassis
    • SINOTRUK Container Side Loader Working With HOWO 8X4 Cargo Truck Chassis
    • SINOTRUK Container Side Loader Working With HOWO 8X4 Cargo Truck Chassis
    • SINOTRUK Container Side Loader Working With HOWO 8X4 Cargo Truck Chassis
  • SINOTRUK Container Side Loader Working With HOWO 8X4 Cargo Truck Chassis

    Product Details:

    Place of Origin: China
    Brand Name: SINOTRUK HOWO
    Certification: ISO/3C/BV/IFA/SGS
    Model Number: 8x4 Cargo truck 37 tons

    Payment & Shipping Terms:

    Minimum Order Quantity: 1 Unit
    Price: USD85000-USD87000/UNIT)negotiation
    Packaging Details: Nude or Waxing in Roro or bulk ship
    Delivery Time: 25 working days after received your advance payment
    Payment Terms: L/C, T/T, Western Union
    Supply Ability: 2,000units per month
    Contact Now
    Detailed Product Description
    Product Name: Container Side Lifter Emission Standard: Euro 2
    Total Length: 11m Max. Lifting Capacity: 37Tons
    Model: 8x4 HOWO Truck Hydralic System: Europe Brand
    Brand: SINOTRUK

    SINOTRUK Container Side Loader working with HOWO 8X4 Cargo truck chassis​



    Description:



    SINOTRUK Container Side Loader working with HOWO 8X4 Cargo truck chassis

    Electro-hydraulic load adaptive patented technology with high and low pressure double pump, and through the combination of flow diverter valve before and after the two hoists for fuel, large flow rate can be achieved at the same time the oil pump in the double under the condition of low pressure and under the condition of high voltage of low pressure pump for small flow high pressure unloading, ensure lifting the efficiency and quality of work. The technology can not only ensure the stability of the crane in high speed switch under the condition of low pressure, but also make full use of the output power of the engine, the economy is better.



    Container crane with lifting chain spin lock technology patent device + automatic storage container handling technology patent lock mechanism for chain rotation, packing operation twist lock in the corner fitting container automatic rotating and locking, will not fall off, to ensure the safety of the operation; transport, spin lock through the limiting device can automatically lock, lift the repetitive operation personnel transport truck loading and receiving chain chain, but also greatly improve the driving safety; after the operation is completed by optimizing the lifting movement track of point and chain position, realize the automatic storage chain boom in the recovery process, greatly improves the operation safety and comfort of vehicle.





    Specification:



    SINOTRUK Container Side Loader working with HOWO 8X4 Cargo truck chassis
    Model 8X4 Cargo truck chassis for 20 feet Container
    Max lifting capacity 37 tons
    Drving Axle HC16, 16ton, 2 Sets
    Engine

    WD615.36, Euro 2, 336hp

    Front axles HF9, 9TonsX2
    Material Carbon steel or Mn steel
    Gross vehicle weight 70000kgs
    Cabin HW76, Single berth, with one bed
    Suspension Normal suspension
    Thickness leaf spring 10/10/10
    Tire/Rim 1200R20, 13pcs, 8.5, 12 pcs
    Brake Chamber Standard 6 pcs
    Spare wheel carrier 2 pcs
    Tool box 1 pcs
    Electrical System Chinese standard 24C lighting system
    Side Maker Lamp LED lamp
    Painting Polyurethane Paint
    Overall dimension 11000×2500×3880(mm)
    Color White, red, green, golden and so on.


    Applications:



    Container Sider Loader which can widespread use in transportation, for all kinds 40 or 20 feets container,

    popular used in sea port.



    Competitive Advantage:



    1) competitive price, cost-effective
    2) quick and efficient spare parts supply bring you more convenient

    3) fast delivery time, we can arrange production according to your needs exactly and quickly

    4) professional import and export dealing procedure, make customs clearance more high efficiency

    5) Adopted imported hydraulic pump, valve and other hydraulic components, lock micro products, to ensure safety and durability

    6) Product is made of high strength steel plate welding, increase the structural strength, reduce the weight of the engine, greatly improving the lifting performance

    7) Hexagon bending forming jib, reduced the horizontal shaking, make the operation more safety; Rotating device is made of high quality rotary support and reducer, make the action more supple and smooth.

    8) External sandblasting processing of tank, internal anti-corrosion treatment, Outside surface adopts advanced polyurethane paint, beautiful appearance

    9) Front and back high spray is optional, water jet diffusion function, 360 degrees of rotation,

    150 degree tilt up and down. Options small flow pump, spraying reel to wake insecticidal garden trees flowers and plants

    10) with all kinds of truck model, which can fulfill your requirement
    11) the key parts adopt the world's top technology products
    12) based on strong technical support and top level technology make the trucks with high quality and

    more reliable
