HOWO 4×2 5-10 Ton Small Refrigerated Box Truck Low Energy Consumption

HOWO 4×2 5-10 Ton Small Refrigerated Box Truck Low Energy Consumption

  • HOWO 4×2 5-10 Ton Small Refrigerated Box Truck Low Energy Consumption
  • HOWO 4×2 5-10 Ton Small Refrigerated Box Truck Low Energy Consumption
  • HOWO 4×2 5-10 Ton Small Refrigerated Box Truck Low Energy Consumption
  • HOWO 4×2 5-10 Ton Small Refrigerated Box Truck Low Energy Consumption
HOWO 4×2 5-10 Ton Small Refrigerated Box Truck Low Energy Consumption
Product Details:
Place of Origin: China
Brand Name: SINOTRUK
Certification: ISO/3C/BV/IFA/SGS
Model Number: ZZ1127G4715C1
Payment & Shipping Terms:
Minimum Order Quantity: 1Unit
Price: Negotiation
Packaging Details: Waxing in Bulk ship, Roro ship, Container
Delivery Time: 10-30 working days
Supply Ability: 3,000 units per month
Contact Now
Detailed Product Description
Chassis Model: ZZ1127G4715C1 Drive Type: 4×2
Engine: YC4E160, 160hp, Euro 3 Transmission: WLY651(6 Forwards & 1 Reverses)
Front Axle: 3.2 Tons Driving Axle: 8.0 Tons
High Light:

160hp Refrigerated Box Truck

,

HOWO 4×2 Refrigerated Box Truck

,

160hp Refrigerated Truck

HOWO 4×2 5-10 Ton Small Refrigerated Box Truck Low Energy Consumption



Description:



Sinotruck howo refrigerator truck or chiller lorry is a van or truck designed to carry perishable freight at low temperatures which is used to transport the frozen or fresh goods, was fitted with the refrigerating unit device and polyurethane thermal insulation van,HOWO cold refrigerated truck is usually used for transporting frozen foods ( freezer truck ), dairy ( milk truck ), vegetables and fruits ( fresh goods transport vehicle ), vaccine and drug ( vaccine vehicles) etc.







Specification:



HOWO 4×2 5-10 Ton Small Refrigerated Box Truck Low Energy Consumption
Chassis Model ZZ1127G4715C1
Drive Type 4×2
Engine YC4E160, 160hp, Euro 3
Cabin 2080 with AC RHD(with one sleeper, air-conditioner and two new-style seat)
Transmission WLY651(6 forwards & 1 reverses)
Front Axle 3.2 Tons
Driving Axle 8.0 Tons
Clutch hydraulically operating with air assistance
Rim/ Tire 8.25R20 (6+1 Spare tire)
Wheel base 4700(mm)
Van board material FRP inner and outer skin, polyurethane insulation material
Dimension of cargo body 6000*2400*2000mm, Bottom:3mm Side:1.5mm
Refrigerator XL-300, -18C0
Overall dimension 8700×2500×3300mm
The curb weight 4355(Kg)
Gross weight 12490 kg
Max. speed 95km/h
Color White, red, green, golden and so on.


Applications:



Refrigerated Truck can widespread use in transportation of all kind of frozen food, vaccinum, vegetables and fruit.



Competitive Advantage:



1) Our company's production of circular easy brand refrigerator car introduced Italy,Germany, the United States overall polyester foam technology, and high strength fiber

plastic and other material manufacturing technology and equipment
2) so that our company refrigeration, heat preservation technology level basic reached world advanced water level.
3) Refrigeration, heat preservation car body with light, high strength, good heat insulation performance, high temperature stability, no pollution, oxidation, easy

maintenance, but also has low noise, low energy consumption, low failure rate, food preservation effect is good and so on a series of advantages
4) A lot of technical indicators and the world's advanced level is close to the fully closed polyurethane plate bonded glass steel structure, this product is light weight, low heat leakage.

5) The "sandwich" structure (low thermal conductivity), good thermal insulation effect. Using unsaturated polyester resin as binder, plus a cushion, with rigid polyurethane foam insulation, heat conduction low coefficient, high strength. High strength plate bonding, high sealing glue, forming a whole. The structure of the refrigerator car is dominant in the domestic market, our company is using the technology of refrigerated trucks.
6) with all kinds of truck model, which can fulfill your requirement
7) the key parts adopt the world's top technology products
8) based on strong technical support and top level technology make the trucks with high quality and more reliable
9) competitive price, cost-effective

HOWO 4×2 5-10 Ton Small Refrigerated Box Truck Low Energy Consumption 0HOWO 4×2 5-10 Ton Small Refrigerated Box Truck Low Energy Consumption 1
