Heavy Duty 12 Tons HIAB Truck Mounted Telescopic Crane 6X4 LHD Truck Cargo Lift

    • Heavy Duty 12 Tons HIAB Truck Mounted Telescopic Crane 6X4 LHD Truck Cargo Lift
    • Heavy Duty 12 Tons HIAB Truck Mounted Telescopic Crane 6X4 LHD Truck Cargo Lift
    • Heavy Duty 12 Tons HIAB Truck Mounted Telescopic Crane 6X4 LHD Truck Cargo Lift
    • Heavy Duty 12 Tons HIAB Truck Mounted Telescopic Crane 6X4 LHD Truck Cargo Lift
  • Heavy Duty 12 Tons HIAB Truck Mounted Telescopic Crane 6X4 LHD Truck Cargo Lift

    Product Details:

    Place of Origin: China
    Brand Name: SINOTRUK HOWO
    Certification: ISO/3C/BV/IFA/SGS
    Model Number: ZZ1257M4341W

    Payment & Shipping Terms:

    Minimum Order Quantity: 1 Unit
    Price: USD56000-USD57000/UNIT)negotiation
    Packaging Details: Nude or Waxing in Roro or bulk ship
    Delivery Time: 25 working days after received your advance payment
    Payment Terms: L/C, T/T, Western Union
    Supply Ability: 2,000units per month
    Contact Now
    Detailed Product Description
    Product Name: Truck Mounted Crane Model: ZZ1257M4341W
    Drive Type: LHD 6X4 Emission Standard: Euro 2
    Engine: WD615.87, 290HP Lifting Capacity: 12Tons

    Truck Mounted Crane 12Tons HIAB for Lifting and goods transportation 6X4 LHD



    Description:



    Truck Mounted Crane 12Tons HIAB for Lifting and goods transportation 6X4 LHD

    Truck Mounted Crane can lift and transport all kinds of goods, widespread use in transportation, civil  construction (including constructional engineering, road and bridge engineering, municipal  constructional engineering, mechanical engineering etc.), landscape sanitation, electricity and  telecommunication industry, field operation, pipeline transportation, stone industry, dock cargo handing and long distance goods transfer. After installed additional device, it can be used for traffic accidents and high altitude rescue.



    Which can choose all kinds of Brand, Such as HOWO, Golden Prince, HOWO A7, Hohan, Engine

    power have 266HP, 290HP, 336HP, 371HP and so on. Emission stand from Euro 2 to Euro5.



    Specification:



    Truck Mounted Crane 12Tons HIAB for Lifting and goods transportation 6X4 LHD

    Chassis Model

    ZZ1257M4341W

    Drive Type

    6×4

    Engine

    WD615.87, 290HP

    Cabin

    HW76 lengthened cab(with one sleeper, air-conditioner and two new-style seat)

    Transmission

    HW15710(10 forwards & 1 reverses)

    Front Axle

    HF9(1X9 Tons)

    Driving Axle

    HC16(2X16Tons)

    Clutch

    hydraulically operating with air assistance

    Rim/ Tire

    11.00R20

    Wheel base

    4400+1350(mm)

    Lifting Capacity

    12 Tons(XCMG, HIAB, or other famouse brand)

    Dimension of cargo body

    6200*2300*600mm, Bottom:3mm Side:1.5mm

    Lifting Height

    14.5m

    Overall dimension

    9520×2500×3475mm

    The curb weight

    10180(Kg)

    Gross weight

    25000 kg

    Max. speed

    95km/h

    Color

    White, red, green, golden and so on.


    Applications:



    Truck Mounted crane can widespread use in transportation, civil construction (including constructional  engineering, road and bridge engineering, municipal constructional engineering, mechanical

    engineering etc.), landscape sanitation, electricity and telecommunication industry.



    Competitive Advantage:



    1) Adopted imported hydraulic pump, valve and other hydraulic components, lock micro products, to  ensure safety and durability

    2) Product is made of high strength steel plate welding, increase the structural strength, reduce the  weight of the engine, greatly improving the lifting performance

    3) Hexagon bending forming jib, reduced the horizontal shaking, make the operation more safety;  Rotating device is made of high quality rotary support and reducer, make the action more supple and  smooth.

    4) External sandblasting processing of tank, internal anti-corrosion treatment,        Outside surface adopts advanced polyurethane paint, beautiful appearance

    5) Front and back high spray is optional, water jet diffusion function, 360 degrees of rotation,

    150 degree tilt up and down. Options small flow pump, spraying reel to wake insecticidal garden trees

    flowers and  plants

    6) with all kinds of truck model, which can fulfill your requirement
    7) the key parts adopt the world's top technology products
    8) based on strong technical support and top level technology make the trucks with high quality and

    more reliable
    9) competitive price, cost-effective
    10) quick and efficient spare parts supply bring you more convenient

    11) fast delivery time, we can arrange production according to your needs exactly and quickly

    12) professional import and export dealing procedure, make customs clearance more high efficiency



    Heavy Duty 12 Tons HIAB Truck Mounted Telescopic Crane 6X4 LHD Truck Cargo LiftHeavy Duty 12 Tons HIAB Truck Mounted Telescopic Crane 6X4 LHD Truck Cargo Lift
