10 Wheels Tipper Dump Truck With 10 Forwards & 2 Reverses Transmission

10 Wheels Tipper Dump Truck With 10 Forwards & 2 Reverses Transmission

    • 10 Wheels Tipper Dump Truck With 10 Forwards & 2 Reverses Transmission
    • 10 Wheels Tipper Dump Truck With 10 Forwards & 2 Reverses Transmission
    • 10 Wheels Tipper Dump Truck With 10 Forwards & 2 Reverses Transmission
    • 10 Wheels Tipper Dump Truck With 10 Forwards & 2 Reverses Transmission
  • 10 Wheels Tipper Dump Truck With 10 Forwards & 2 Reverses Transmission

    Product Details:

    Place of Origin: China
    Brand Name: SINOTRUK HOWO
    Certification: ISO/3C/BV/IFA/SGS
    Model Number: ZZ3257N3847A

    Payment & Shipping Terms:

    Minimum Order Quantity: 1 Unit
    Price: USD40000-USD42000/UNIT)negotiation
    Packaging Details: Nude or Waxing in Roro or bulk ship
    Delivery Time: 25 working days after received your advance payment
    Payment Terms: L/C, T/T, Western Union
    Supply Ability: 3,000units per month
    Contact Now
    Detailed Product Description
    Product Name: Tipper Dump Truck Model: ZZ3257N3847A
    Drive Type: RHD 6X4 Emission Standard: Euro 2
    Wheel: 10 Wheels Cargo Body: 5800*2300*1500mm
    Wheel Base: 3800+1350(mm)

    10 Wheels Tipper Dump Truck With 10 Forwards & 2 Reverses Transmission



    Tipper Dump Truck Description:



    Be comprehensive with Euro2 and Euro3 engine equipped.
    Driving type: 4×2, 4×4 6×2, 6×6 ,6×4, 8×4 and so on.

    Power range: 266HP - 420HP.



    Tipper Dump Truck Features



    Engine

    • Engine brand: SINO BRAND
    • Engine model: WD615.47 Euro II
    • Engine type: 6-cylinder in line, 4-stroke, water-cooled, turbocharged, air-to-air intercooled, direct injection
    • Displacement: 9.726 liters
    • Max. output: 371hp@2200rpm

    Max torque: 1460NM@1100-1600rpm



    Tipper Dump Truck Specification:



    10 Wheels Tipper Dump Truck With 10 Forwards & 2 Reverses Transmission
    Model ZZ3257N3847A
    Drive Type 6×4
    Cabin HW76 lengthened cab(with one sleeper, air-conditioner and new-style seat)
    Transmission HW19710(10 forwards & 2 reverses)
    Front Axle 1×HF9 ( 9 Tons)
    Driving Axle HC16, 16Tons
    Steering ZF8118 hydraulic steering with power assistance.
    Clutch

    Single-plate dry coil-spring clutch, diameter 430mm, hydraulically operating with

    air assistance

    Rim/ Tire 11.00R20,12.00R20,12.00R24 Radial tire
    Wheel base 3800+1350(mm)
    Overall dimension 8575×2496×3450(mm)
    Cargo body

    5800×2300×1500(mm),Bottom:8mm, Side:6mm

    The curb weight 12200(Kg)
    Gross weight 25000 kg
    Max. speed 75km/h
    Color White, red, green, golden and so on.



    The charateristics and advantages:



    The lowest gravity center : The gravity center is 150-350mm lower than other present domestic dump trucks , it is the lowest gravity center dump truck at home .



    The lightest self-weight :



    Comparing to the other domestic dump trucks with the same structures , its self-weight is the lightest.



    Reformative body structure :



    The body is multilateral Ustructure with high rigidity. The rear hinge is 100-350mm wider than other domestic square bodys, and this structure can improve the lifting stability.



    10 Wheels Tipper Dump Truck With 10 Forwards & 2 Reverses Transmission10 Wheels Tipper Dump Truck With 10 Forwards & 2 Reverses Transmission
