Low Fuel Consumption Tipper Dump Truck For Mining Industry / Construction

    • Low Fuel Consumption Tipper Dump Truck For Mining Industry / Construction
    • Low Fuel Consumption Tipper Dump Truck For Mining Industry / Construction
    • Low Fuel Consumption Tipper Dump Truck For Mining Industry / Construction
    • Low Fuel Consumption Tipper Dump Truck For Mining Industry / Construction
  • Low Fuel Consumption Tipper Dump Truck For Mining Industry / Construction

    Product Details:

    Place of Origin: China
    Brand Name: SINOTRUK HOWO
    Certification: ISO/3C/BV/IFA/SGS
    Model Number: ZZ3257N3847A

    Payment & Shipping Terms:

    Minimum Order Quantity: 1 Unit
    Price: USD40000-USD42000/UNIT)negotiation
    Packaging Details: Nude or Waxing in Roro or bulk ship
    Delivery Time: 25 working days after received your advance payment
    Payment Terms: L/C, T/T, Western Union
    Supply Ability: 3,000units per month
    Contact Now
    Detailed Product Description
    Cargo Body: 5800*2300*1500mm Product Name: Tipper Dump Truck
    Loading Capacity: 30-40tons Model: ZZ3257N3847A
    Drive Type: RHD 6X4 Emission Standard: Euro 2
    Engine: WD615.47, 371HP

     Low Fuel Consumption Tipper Dump Truck For Mining Industry / Construction



    Tipper Dump Truck Description:



    A Tipper Dump Truck is a truck used to convey loose materials like sands, pebbles, soils, building materials, coals, ores, crops, farm products, etc. A dump truck is usually installed with a hydraulic motivated open-box bed hinged at the rear. The front of this open-box can be lifted up so that the materials are discharged on the ground behind the truck.





    Tipper Dump Truck Specification:



    Low Fuel Consumption Tipper Dump Truck For Mining Industry / Construction

    Model ZZ3257N3847A
    Drive Type 6×4
    Engine

    WD615.47 , 371HP( Euro II)

    6 cylinder in-line with water cooling, turbo-charging & inter-cooling,4 stroke electronic fuel injection diesel engine

    Displacement : 9.726L

    Cabin HW76 lengthened cab(with one sleeper, air-conditioner and new-style seat)
    Transmission HW19710(10 forwards & 2 reverses)
    Front Axle 1×HF9 ( 9 Tons)
    Driving Axle HC16, 16Tons
    Steering ZF8118 hydraulic steering with power assistance.
    Clutch

    Single-plate dry coil-spring clutch, diameter 430mm, hydraulically operating with

    air assistance

    Rim/ Tire 11.00R20,12.00R20,12.00R24 Radial tire
    Wheel base 3800+1350(mm)
    Overall dimension 8575×2496×3450(mm)
    Cargo body

    5800×2300×1500(mm),Bottom:8mm, Side:6mm

    The curb weight 12200(Kg)



    Our Advantage:

    • competive price, cost-effective
    • with all kinds of truck model, which can fulfil your requirements
    • all kinds of cargo body structure can be designed and produced according to your request,
    • make it have light curb weight , high rigidity , high loading capacity
    • using the high strength steel, make it has a long service life
    • The optimized hydraulic control system helps to avoid wrong operation, it has higher
    • safety and running efficiency.
    • excellant apperance of cabin, safety, reliable
    • quick and efficient spare parts supply bring you more convenient



    Tipper Dump Truck Details



    Low Fuel Consumption Tipper Dump Truck For Mining Industry / ConstructionLow Fuel Consumption Tipper Dump Truck For Mining Industry / Construction
