Place of Origin: | China |
Brand Name: | SINOTRUK HOWO A7 |
Certification: | ISO/3C/BV/IFA/SGS |
Model Number: | ZZ3257M3847N1 |
Minimum Order Quantity: | 1 Unit |
---|---|
Price: | USD38000-USD42000/UNIT)negotiation |
Packaging Details: | Nude or Waxing in Roro or bulk ship |
Delivery Time: | 25 working days after received your advance payment |
Payment Terms: | L/C, T/T, Western Union |
Supply Ability: | 3,000units per month |
Product Name: | Construction Tipper Truck | Model: | ZZ3257M3847N1 |
---|---|---|---|
Drive Type: | RHD 6X4 | Engine: | WD615.87, 290HP |
Cargo Body: | 5800*2300*1500mm | Loading Capacity: | 30-40tons |
Cabin: | A7-P | Transmission: | HW13710 |
High Light: | heavy dump truck,sinotruk howo dump truck |
Tipper Truck SINOTRUK HOWO A7 Front Lifting 30 - 40tons RHD 6X4 for Construction
Description:
A Dump Truck Is A Truck Used To Convey Loose Materials Like Sands, Pebbles, Soils, Building Materials, Coals, Ores, Crops, Farm Products, Etc. A Dump Truck Is Usually Installed With A Hydraulic Motivated Open-Box Bed Hinged At The Rear. The Front Of This Open-Box Can Be Lifted Up So That The Materials Are Discharged On The Ground Behind The Truck.
Specifications:
SINOTRUK HOWO A7 Dump Truck 30 - 40tons RHD 6X4 for Construction material loading | ||||
Model | ZZ3257M3847N1 | |||
Drive Type | 8×4 | |||
Engine |
|
|||
Cabin | A7-P lengthened cab(with one sleeper, air-conditioner and new-style seat) | |||
Transmission | HW13710(10 forwards & 2 reverses) | |||
Front Axle | 1×HF9 ( 9 Tons) | |||
Driving Axle | HC16, 16Tons | |||
Steering | ZF8118 hydraulic steering with power assistance. | |||
Clutch |
Single-plate dry coil-spring clutch, diameter 430mm, hydraulically operating with air assistance |
|||
Rim/ Tire | 11.00R20,12.00R20,12.00R24 Radial tire | |||
Wheel base | 3800+1350(mm) | |||
Overall dimension | 8575×2496×3450(mm) | |||
Cargo body | 5800×2300×1500(mm),Bottom:8mm, Side:6mm | |||
The curb weight | 12300(Kg) | |||
Gross weight | 25000 kg | |||
Max. speed | 75km/h | |||
Color | White, red, green, golden and so on. |
Applications:
working for Mining industry, Construction business, docks, to transport soil, sand, stones and so on.
Competitive Advantage:
1)with all kinds of truck model, which can fulfil your requirement
2)the key parts adopt the world's top technology products
3)based on strong technical support and top level technology make the trucks with high
quality and more reliable
4)Optimized cargo body structure,light weight,high rigidity,large loading capacity
5)Using the high strength steel,it has long service life
6)Optimized the sealing structure has the better sealing effect.
7)The intelligent hydraulic control system helps to avoid error operation, it has higher safety and running
efficiency.
8)Multiple box structures and device selections
9)low fuel consumption
10) strong enough engine
11)competive price, cost-effective
12)quick and efficient spare parts supply bring you more convenient
13)fast delivery time, we can arange production according to your needs exactly and
quickly
14) professional import and export dealing precedure, make customs clearance more high efficiency
After 10 years of struggle, China National Heavy Duty Truck Group Co. Ltd. has grown into the heavy truck has greater influence and coverage of backbone enterprises.
Our services
Reply your inquiry in 12 working hours;
Experienced staffs answer all your questions;
Customer’s design is available for certain products(OEM);
Spare parts for all types of engine machinery with reasonable price;
Different kinds of semi trailer can be provided with competitive price.
SINOTRUK INTERNATIONAL CO., LTD. specializes in complete trucks , mid trucks as well as light trucks together with all the original and good quality spare parts for HOWO and other series trucks, We sell to various military transporting troops, oil and gas transporting troops, coal transporting troops and engineering teams at home and abroad. Now our products have been exported to China, Russia, the Middle East, Africa, southeast Asia, South America and other countries and regions.
