Red Color SINOTRUK HOWO 6x4 Dump Truck 266HP LHD Type

Red Color SINOTRUK HOWO 6x4 Dump Truck 266HP LHD Type

  • Red Color SINOTRUK HOWO 6x4 Dump Truck 266HP LHD Type
  • Red Color SINOTRUK HOWO 6x4 Dump Truck 266HP LHD Type
  • Red Color SINOTRUK HOWO 6x4 Dump Truck 266HP LHD Type
  • Red Color SINOTRUK HOWO 6x4 Dump Truck 266HP LHD Type
Red Color SINOTRUK HOWO 6x4 Dump Truck 266HP LHD Type
Product Details:
Place of Origin: China
Brand Name: SINOTRUK
Certification: ISO/3C/BV/IFA/SGS
Model Number: ZZ3257M4147W
Payment & Shipping Terms:
Minimum Order Quantity: 1Unit
Price: Negotiation
Packaging Details: Waxing in Bulk ship, Roro ship, Container
Delivery Time: 10-30 working days
Supply Ability: 3,000 units per month
Contact Now
Detailed Product Description
Model: ZZ3257M4147W Drive Type: 6×4
Transmission: HW15710(10 Forwards & 2 Reverses) Cabin: HW76
Front Axle: 1×HF9 ( 9 Tons) Driving Axle: 2XHC16, 16Tons
High Light:

Red Dump Truck 6x4

,

266HP HOWO 6x4 Dump Truck

,

Red HOWO 6x4 Dump Truck

SINOTRUK HOWO 6x4 266HP LHD Dump Truck In Red Color



Description:

Tipper Truck SINOTRUK HOWO Front Lifting 30 - 40tons LHD 6X4 for Construction

This type product , with features of reliable structure , high loading capacity which can load 30-40tons,strong power from 266HP to 420HP, reliable performance and wide acceplication.



This model can meet the requirements of severe environment like construction site and mining area.which can fullfiled you of short distance transportation of mining rock and soil as well as engineering construction.







Specifications:




SINOTRUK HOWO Dump Truck 30 - 40tons LHD 6X4 for Construction material loading
Model ZZ3257M4147W
Drive Type 6×4
Engine
WD615.62 , 266 HP( Euro II)
6 cylinder in-line with water cooling, turbo-charging & inter-cooling,4 stroke electronic fuel injection diesel engine
Displacement : 9.726L
Cabin HW76 lengthened cab(with one sleeper, air-conditioner and new-style seat)
Transmission HW15710(10 forwards & 2 reverses)
Front Axle 1×HF9 ( 9 Tons)
Driving Axle 2XHC16, 16Tons
Steering ZF8118 hydraulic steering with power assistance.
Clutch

Single-plate dry coil-spring clutch, diameter 430mm, hydraulically operating with

air assistance

Rim/ Tire 11.00R20,12.00R20,12.00R24 Radial tire
Wheel base 4125+1350(mm)
Overall dimension 8845×2496×3170(mm)
Cargo body 6000×2300×1200(mm),Bottom:8mm, Side:6mm
The curb weight 12280(Kg)
Gross weight 25000 kg
Max. speed 75km/h
Color White, red, green, golden and so on.


Applications:



working for Mining industry, Construction business, docks, to transport soil, sand, stones and so on.



Competitive Advantage:



1) with all kinds of truck model, which can fulfil your requirement
2) the key parts adopt the world's top technology products
3) based on strong technical support and top level technology make the trucks with high quality and more reliable

4) Optimized cargo body structure,light weight,high rigidity,large loading capacity

5) Using the high strength steel,it has long service life

6) Optimized the sealing structure has the better sealing effect.

7) The intelligent hydraulic control system helps to avoid error operation, it has higher safety and running efficiency.

8) Multiple box structures and device selections

9) low fuel consumption
10) strong enough engine

11) competive price, cost-effective
12) quick and efficient spare parts supply bring you more convenient
13) fast delivery time, we can arange production according to your needs exactly and quickly

14) professional import and export dealing precedure, make customs clearance more high efficiency

Red Color SINOTRUK HOWO 6x4 Dump Truck 266HP LHD Type 0Red Color SINOTRUK HOWO 6x4 Dump Truck 266HP LHD Type 1
