SINOTRUK INTERNATIONAL CO., LTD.
Sales & Support:
 |
| Place of Origin: | China |
| Brand Name: | SINOTRUK |
| Certification: | ISO/3C/BV/IFA/SGS |
| Model Number: | ZZ3257V384JB1 |
| Minimum Order Quantity: | 1Unit |
|---|---|
| Price: | Negotiation |
| Packaging Details: | Waxing in Bulk ship, Roro ship, Container |
| Delivery Time: | 10-30 working days |
| Supply Ability: | 3,000 units per month |
| Product Name: | Tipper Dump Truck | Model: | ZZ3257V384JB1 |
|---|---|---|---|
| Drive Type: | LHD 6X4 | Cab: | N76L With One Sleeper, A/C |
| Engine: | WD615.47, 371HP | Transmission: | HW19710(10 Forwards & 2 Reverses) |
| High Light: | 371hp howo 6x4 dump truck,euro 2 howo 6x4 dump truck,construction howo dump trucks |
||
SINOTRUK HOWO 6x4 LHD Big Tipper Dump Trucks 371HP
Description:
Tipper Truck SINOTRUK HOWO Front Lifting 30 - 40tons LHD 6X4 for Construction
This type product , with features of reliable structure , high loading capacity which can load 30-40tons,strong power from 266HP to 420HP, reliable performance and wide acceplication.
This model can meet the requirements of severe environment like construction site and mining area.which can fullfiled you of short distance transportation of mining rock and soil as well as engineering construction.
Specifications:
| SINOTRUK HOWO 6x4 LHD Big Tipper Dump Trucks 371HP | ||||
| Model | ZZ3257V384JB1 | |||
| Drive Type | 6×4 | |||
| Engine |
|
|||
| Cabin | N76L(with one sleeper, air-conditioner and new-style seat) | |||
| Transmission | HW19710(10 forwards & 2 reverses) | |||
| Front Axle | 1×HF9 ( 9 Tons) | |||
| Driving Axle | 2XHC16, 16Tons | |||
| Steering | ZF8118 hydraulic steering with power assistance. | |||
| Clutch |
Single-plate dry coil-spring clutch, diameter 430mm, hydraulically operating with air assistance |
|||
| Rim/ Tire | 11.00R20,12.00R20,12.00R24 Radial tire | |||
| Wheel base | 3800+1350(mm) | |||
| Overall dimension | 8550×2496×3450(mm) | |||
| Cargo body | 5800×2300×1500(mm),Bottom:8mm, Side:6mm | |||
| The curb weight | 12100(Kg) | |||
| Gross weight | 25000 kg | |||
| Max. speed | 75km/h | |||
| Color | White, red, green, golden and so on. | |||
Applications:
working for Mining industry, Construction business, docks, to transport soil, sand, stones and so on.
Competitive Advantage:
1.Good cargo body structure, high rigidity, hight loading capacity.
2.Good sealing structure has the better sealing effect.
3.The advanced hydraulic control system helps to avoid wrong operation, it has higher safety and running efficiency.
4.The whole truck structure has characteristics lower center of gravity,with higher security when lifting the cargo body.
5. Wonderful apperance of cabin, safety, reliable.
6. Lower fuel consumption.
7. Enough strong engine power.
Contact Person: Mr. Aaron White
Tel: +86-13210598479
Fax: 86-531-85865823
