Place of Origin: | China |
Brand Name: | SINOTRUK |
Certification: | ISO/3C/BV/IFA/SGS |
Model Number: | ZZ3259N384PB3 |
Minimum Order Quantity: | 1units |
---|---|
Price: | Negotiation |
Packaging Details: | Waxing in Bulk ship, Roro ship, Container |
Delivery Time: | 10-30 working days |
Supply Ability: | 3,000 units per month |
Product Name: | Tipper Dump Truck | Model: | ZZ3259N384PB3 |
---|---|---|---|
Drive Type: | LHD 6X4 | Emission Standard: | Euro 2 |
Engine: | WD615.47, 371HP | Loading Capacity: | 30tons |
High Light: | HOWO Tipper Truck 30t,HOWO Tipper Truck Left Hand Drive,Euro2 HOWO Tipper Truck |
SINOTRUK 6X4 LHD Mining Tipper Dump Truck 371HP 30 Tons Euro2
Description:
Mining Tipper Dump Truck 6X4 LHD 371HP 30 tons SINOTRUK HOWO for Mining industry
The new front axle assembly independently developed by Sinotruk adopts all-cast stranded beam and 500x210 reinforced brake for the assembly technology of truck parts.
The rear axle adopts AC26 mining drive axle, the main reducer structure design is more reasonable, reinforced casting axle housing and drum brake, the vehicle bearing capacity and braking capacity is in the leading level in China.
Configuration HW19710 transmission, HW70 power, torque up to 700NM.
Equipped with 500 litre Type D fuel tank (optional 400 litre fuel tank), the workload of the vehicle meets your requirements.
Wheels and tires :10.0/2-25 wheel assembly, standard 14.00-25-36PR tires, original 14.00R25-36PR tires, is specially customized for mine Bawang special tires with high bearing capacity and high wear resistance.
HOWO mine dump truck adopts single side high strength frame cab, simple shape, hard, wide vision; Good sealing can ensure that your vehicle is always in a safe and comfortable driving environment; There are two lights on the front and rear tops of the engine room for night work.
Specification:
SINOTRUK 6X4 LHD Mining Tipper Dump Truck 371HP 30 Tons | ||||
Model | ZZ3259N384PB3 | |||
Drive Type | 6×4 | |||
Engine |
|
|||
Cabin | WR-D (with air-conditioner and new-style seat) | |||
Transmission | HW19710(10 forwards & 2 reverses) | |||
Front Axle | 1×HF9 ( 9 Tons) | |||
Driving Axle | HC16 | |||
Steering | ZF8098 hydraulic steering with power assistance. | |||
Clutch | Single-plate dry coil-spring clutch, diameter 430mm, hydraulically operating with air assistance | |||
Rim/ Tire | 12.00R20 radial tyres with one spare tyre | |||
Wheel base | 3825+1350(mm) | |||
Overall dimension | 8545×2580×3410(mm) | |||
Cargo body | 5800×2300×1300(mm) | |||
The curb weight | 23000(Kg) | |||
Gross weight | 70000 kg | |||
Max. speed | 50km/h | |||
Color | White, red, green, golden and so on. |
Applications:
HOWO 30 Mining Dump Truck is heavy concentrated engineering design personnel and development, first and foremost applies to all kinds of open pit coal mine, steel mills, hydropower construction, dock, poor road conditions, homework is in bad situations in areas within a short distance transport business development of this car, in terms of the particular user groups, with high economic benefit and social benefit.
Competitive Advantage:
1) competive price, cost-effective
2) low fuel consumption
3) strong enough engine
4) with all kinds of truck model, which can fulfil your requirements
5) based on strong technical support and top level technology make the trucks with high quality and more reliable
6) The front lifting type domestic advanced hydraulic control system helps to avoid wrong operation, it has higher
7) the key parts adopt the world's top technology products
8) all kinds of cargo body structure can be designed and produced according to your request, make it have light curb weight , high rigidity , high loading capacity
9) using the high strength steel, make it has a long service life safety and running efficiency.
10) excellant apperance of cabin, safety, reliable
11) quick and efficient spare parts supply bring you more convenient
12) fast delivery time, we can arange production according to your needs exactly and quickly
13) professional import and export dealing precedure, make customs clearance more high efficiency
