| Place of Origin: | China |
| Brand Name: | SINOTRUK HOWO |
| Certification: | ISO/3C/BV/IFA/SGS |
| Model Number: | ZZ3317V386JB1R |
| Minimum Order Quantity: | 1 Unit |
|---|---|
| Price: | Negotiation |
| Packaging Details: | Nude or Waxing in Roro or bulk ship |
| Delivery Time: | 10-30 working days |
| Payment Terms: | L/C, T/T |
| Supply Ability: | 3,000 units per month |
| Model: | ZZ3317V386JB1R | Engine: | WD615.47, 371HP |
|---|---|---|---|
| Cabin: | HOWO H77L | Transmission: | HW19710+HW50 |
| Fuel Tank: | 400L | Cargo Body: | 7800×2300×1500mm，26.91 CBM, Floor 8 Side 6 Mm. |
| High Light: | SINOTRUK HOWO Wipper Dump Truck,White HOWO 8X4 Dump Truck,Wipper Dump Truck 371HP |
||
SINOTRUK HOWO Wipper Dump Truck RHD 8×4 371HP
Sinotruk HOWO 8X4 Dump Truck 371hp 12 Wheels White H77L
Description:
HOWO dump trucks, also called dump trucks or dump trucks, are used to transport construction waste (sand, gravel, demolition waste, etc.) and coal. A typical HOWO dump truck is fitted with an open box bed hinged at the rear and fitted with hydraulic sliders to raise the front so that the bed material at the delivery site is at the rear of the truck. .
Specifications:
| Sinotruk HOWO 8X4 Dump Truck 371hp 12 Wheels H77L | ||||
| Model | ZZ3317V386JB1R | |||
| Drive Type | 8×4 | |||
| Engine |
|
|||
| Cabin | H77L | |||
| Transmission | HW19710(10 forwards & 2 reverses) | |||
| Front Axle | 2×VGD95 ( 9.5 Tons) | |||
| Driving Axle | 2XHC16, 16Tons | |||
| Steering | BOSCH | |||
| Clutch |
Single-plate dry coil-spring clutch, diameter 430mm, hydraulically operating with air assistance |
|||
| Rim/ Tire | 315/80R22.5,12.00R20 18PR,11.00R20 | |||
| Wheel base | 3825+1350(mm) | |||
| Overall dimension | 10965×2600×3450(mm) | |||
| Cargo body | 7800×2300×1500(mm),Bottom:8mm, Side:6mm | |||
| The curb weight | 15200(Kg) | |||
| Gross weight | 31000 kg | |||
| Max. speed | 80km/h | |||
| Color | White, red, green, golden and so on. | |||
Applications:
Applicable to mining, construction, wharf, transport soil, sand, stone and other industries.
Competitive Advantage:
1) Different types of trucks to meet your needs
2) The world's top technology products are adopted for key components
3) Based on strong technical support and advanced technology, make the truck better quality and more reliable
4) Optimized loading structure, light weight, high rigidity, large load capacity
5) Adopt high tensile steel, long service life
6) Optimized sealing structure has better sealing effect.
7) Intelligent hydraulic control system, avoid operation error, with higher safety and operation efficiency.
8) A variety of box structure and equipment selection
9) Low fuel consumption
10) The motor is quite powerful
11) Competitive price, cost effective
12) Quick and efficient supply of spare parts, bring you more convenience
13) Fast delivery time, we can accurately and quickly arrange production according to your requirements
14) Professional import and export procedures make customs clearance more efficient
