Red SINOTRUK HOWO 8X4 Dump Truck 400hp 12 Wheels

Red SINOTRUK HOWO 8X4 Dump Truck 400hp 12 Wheels

  • Red SINOTRUK HOWO 8X4 Dump Truck 400hp 12 Wheels
  • Red SINOTRUK HOWO 8X4 Dump Truck 400hp 12 Wheels
  • Red SINOTRUK HOWO 8X4 Dump Truck 400hp 12 Wheels
  • Red SINOTRUK HOWO 8X4 Dump Truck 400hp 12 Wheels
Red SINOTRUK HOWO 8X4 Dump Truck 400hp 12 Wheels
Product Details:
Place of Origin: China
Brand Name: SINOTRUK
Certification: ISO/3C/BV/IFA/SGS
Model Number: ZZ3317V3567B1
Payment & Shipping Terms:
Minimum Order Quantity: 1unit
Price: Negotiation
Packaging Details: Waxing in Bulk ship, Roro ship, Container
Delivery Time: 10-30 working days
Supply Ability: 3,000 units per month
Contact Now
Detailed Product Description
Model: ZZ3317V3567B1 Engine: WP12.400E201 , 400 HP
Drive Type: Left Hand Drive(optional) Steering: BOSCH
Front Axle: 2×VGD95 Driving Axle: 2XHC16
High Light:

SINOTRUK HOWO 8X4 Dump Truck

,

HOWO Dump Truck 400hp

,

12 Wheels HOWO Dump Truck

SINOTRUK HOWO 8×4 12wheels Dump truck 400HP for Mining



Description:



HOWO dump trucks, also known as dump trucks or dump trucks, are used to transport construction waste (such as sand, gravel, or demolition waste) as well as coal. A typical HOWO dump truck is equipped with an open-box bed which is hinged at the rear and equipped with hydraulic sliders to lift the front so that the bed material at the delivery site is deposited (dumped) on the ground behind the truck.





Specifications:


SINOTRUK HOWO 8×4 12wheels Dump truck 400HP for Mining
Model ZZ3317V3567B1
Drive Type 8×4
Engine
WP12.400E201,400 HP( Euro II)
6 cylinder in-line with water cooling, turbo-charging & inter-cooling,4 stroke electronic fuel injection diesel engine
Displacement : 11.596L
Cabin HW76 lengthened cab(with one sleeper, air-conditioner and new-style seat)
Transmission HW19710(10 forwards & 2 reverses)
Front Axle 2×VGD95 ( 9.5 Tons)
Driving Axle 2XHC16, 16Tons
Steering BOSCH
Clutch

Single-plate dry coil-spring clutch, diameter 430mm, hydraulically operating with

air assistance

Rim/ Tire 12.00R20 Radial tire
Wheel base 3500+1400(mm)
Overall dimension 10945×2600×3450(mm)
Cargo body 7800×2300×1500(mm),Bottom:8mm, Side:6mm
The curb weight 12250(Kg)
Gross weight 25000 kg
Max. speed 75km/h
Color White, red, green, golden and so on.


Applications:



working for Mining industry, Construction business, docks, to transport soil, sand, stones and so on.



Competitive Advantage:



1) Various types of trucks to meet your needs
2) The world's top technology products are adopted for key components
3) Based on strong technical support and top technology, make the truck higher quality and more reliable

4) Optimized cargo structure, light weight, high rigidity, large load capacity

5) Adopt high strength steel, long service life

6) The optimized sealing structure has better sealing effect.

7) Intelligent hydraulic control system, avoid misoperation, with higher safety and operation efficiency.

8) A variety of box structure and equipment selection

9) Low fuel consumption
10) The engine is strong enough

11) Competitive price, cost-effective
12) Fast and efficient spare parts supply, bring you more convenience
13) Fast delivery time, we can accurately and quickly arrange production according to your needs

14) Professional import and export transaction procedures make customs clearance more efficient
