HOWO N7 LHD 12wheels 8X4 400HP Dump Truck For Mining

HOWO N7 LHD 12wheels 8X4 400HP Dump Truck For Mining

  • HOWO N7 LHD 12wheels 8X4 400HP Dump Truck For Mining
  • HOWO N7 LHD 12wheels 8X4 400HP Dump Truck For Mining
  • HOWO N7 LHD 12wheels 8X4 400HP Dump Truck For Mining
  • HOWO N7 LHD 12wheels 8X4 400HP Dump Truck For Mining
HOWO N7 LHD 12wheels 8X4 400HP Dump Truck For Mining
Product Details:
Place of Origin: China
Brand Name: SINOTRUK HOWO
Certification: ISO/3C/BV/IFA/SGS
Model Number: ZZ3317V356JB1
Payment & Shipping Terms:
Minimum Order Quantity: 1 Unit
Price: Negotiation
Packaging Details: Nude or Waxing in Roro or bulk ship
Delivery Time: 10-30 working days
Payment Terms: L/C, T/T
Supply Ability: 3,000 units per month
Contact Now
Detailed Product Description
Engine: WP12.400E201, Euro2, 400HP, Fuel Type: Diesel
Drive Type: LHD 6X4 Model: ZZ3317V356JB1
Cargo Box: 20m³
High Light:

LHD 8X4 Dump Truck

,

12wheels HOWO 8X4 Dump Truck

,

LHD HOWO 8X4 Dump Truck

HOWO N7 LHD 12wheels 8X4 400HP Dump Truck For Mining

Description:

This truck is famous both abroad and domestically.

The whole appearance looks quite noble, and the touch of the body can meet the needs of young people. The front of the air intake and the bright stripe decoration look very classy, the headlights are particularly sharp and dazzling, especially at night when they are illuminated. The rear configuration is also rounded, the whole corresponds to the feeling of a heavy tractor, the movement of the 12R22.518PR rim looks more dynamic. In short, superior family planning language underscores the quality of the maker's conscience.

Specifications:


HOWO N7 LHD 12wheels 8X4 400HP Dump Truck For Mining
Model ZZ3317V356JB1
Drive Type 8×4
Engine
WP12.400E201,400 HP( Euro II)
6 cylinder in-line with water cooling, turbo-charging & inter-cooling,4 stroke electronic fuel injection diesel engine
Displacement : 11.596L
Cabin HOWO N7W lengthened cab(with one sleeper, air-conditioner and new-style seat)
Transmission HW19710(10 forwards & 2 reverses)
Front Axle 2×VGD95 ( 9.5 Tons)
Driving Axle 2XHC16, 16Tons
Steering BOSCH
Clutch

Single-plate dry coil-spring clutch, diameter 430mm, hydraulically operating with

air assistance

Rim/ Tire 12.00R20 Radial tire
Wheel base 3825+1350(mm)
Overall dimension 10945×2600×3450(mm)
Cargo body 7800×2300×1500(mm),Bottom:8mm, Side:6mm
The curb weight 12250(Kg)
Gross weight 25000 kg
Max. speed 75km/h
Color White, red, green, golden and so on.



Applications:



Applicable to mining, construction, wharf, transport soil, sand, stone and other industries.





Competitive Advantage:

1) Various types of trucks can meet your needs
2) The world's leading technology products are used for key components
3) The Sinotruk manual gearbox is selected as the gearbox. No frustration with daily driving. Thanks to Sinotruk Haohan's excellent training ability, the engine and transmission cooperate with each other.

4) More active accelerator pedal response, no need to step on the accelerator pedal, also can feel the power feedback, let car users feel the control is fun.

5) In terms of comfort, Haohan N7W has made great efforts to create driving comfort, and the driving space is satisfactory and comfortable enough.

6) The optimized sealing structure has better sealing effect.

7) Intelligent hydraulic control system, avoid misoperation, higher safety and operation efficiency.

8) A variety of box structures and equipment choices

Fuel consumption is low and performance is very good for such a large truck
10) The motor is powerful enough

11) Competitive price, cost effective
12) Fast and efficient supply of spare parts for more convenience
13) Fast delivery times, we can organize production according to your needs accurately and quickly

14) Professional import and export transaction process to make customs clearance more efficient
