Sinotruk Howo Mining Tipper Dump Truck 90Tons 6 × 4 High Strength Steel Cargo Body

Sinotruk Howo Mining Tipper Dump Truck 90Tons 6 × 4 High Strength Steel Cargo Body

  • Sinotruk Howo Mining Tipper Dump Truck 90Tons 6 × 4 High Strength Steel Cargo Body
  • Sinotruk Howo Mining Tipper Dump Truck 90Tons 6 × 4 High Strength Steel Cargo Body
  • Sinotruk Howo Mining Tipper Dump Truck 90Tons 6 × 4 High Strength Steel Cargo Body
  • Sinotruk Howo Mining Tipper Dump Truck 90Tons 6 × 4 High Strength Steel Cargo Body
Sinotruk Howo Mining Tipper Dump Truck 90Tons 6 × 4 High Strength Steel Cargo Body
Product Details:
Place of Origin: China
Brand Name: SINOTRUK
Certification: ISO/3C/BV/IFA/SGS
Model Number: ZZ5707V384L
Payment & Shipping Terms:
Minimum Order Quantity: 1units
Price: Negotiation
Packaging Details: Waxing in Bulk ship, Roro ship
Delivery Time: 10-30 working days
Supply Ability: 2,000 units per month
Contact Now
Detailed Product Description
Product Name: Tipper Dump Truck Model: ZZ5707V384L
Drive Type: 6X4 Emission Standard: Euro 2
Engine: WP12.430E201 Loading Capacity: 90Tons
High Light:

High Strength Steel Tipper Dump Truck

,

6 × 4 Tipper Dump Truck

,

90Tons Tipper Dump Truck

Sinotruk Howo Mining Tipper Dump Truck 90Tons 6 × 4 High Strength Steel Cargo Body



Description:



Sinotruk Howo Mining Tipper Dump Truck 90Tons 6 × 4 High Strength Steel Cargo Body

SINOTRUK independent research and development of new front axle assembly, the application of the whole casting strander beam, 500x210 strengthen type brake for truck parts assembly technology.

Rear axle adopts 35 mine driving axle, the main reducer structure design more reasonable, strengthen type casting bridge shell and drum brake the vehicle carrying capacity and braking ability in the leading domestic level.





The configuration of the HW21712 gearbox, HW70 force, torque up to 700NM.

Equipped with a 500 liter D type fuel tank (optional 400 liters fuel tank), the workload of vehicle to meet your requirements.

Wheel and tyre: 10.0/2-25 wheel assembly, the standard 14.00-25-36PR tire, the original 14.00R25-36PR tire, is specifically for mines overlord customization of high load capacity, high wear-resistant special tires.



HOWO Mining Dump Truck with unilateral high strength skeleton cab, modelling concise, hale and hearty, broaden their horizons; good sealing can ensure your vehicle is always in the safe and comfortable driving environment; there are each of the two lighting lamps at the top of cabin's front and back for night work.





Specification:



Sinotruk Howo Mining Tipper Dump Truck 90Tons 6 × 4 High Strength Steel Cargo Body
Model ZZ5707V384L
Drive Type 6×4
Engine
WP12.430E201 , 430HP( Euro II)
6 cylinder in-line with water cooling, turbo-charging & inter-cooling,4 stroke electronic fuel injection diesel engine
Displacement : 11.596L
Cabin HW7D unilateral high strength skeleton cab(with one sleeper, air-conditioner and new-style seat)
Transmission HW21712(12 forwards & 2 reverses)
Front Axle 20 Tons
Driving Axle 2 × 35Tons
Steering hydraulic steering with power assistance.
Clutch Single-plate dry coil-spring clutch, diameter 430mm, hydraulically operating with air assistance
Rim/ Tire 14.00-25,14.00R25,Radial tire
Wheel base 3800+1350(mm)
Overall dimension 8800×3300×4100(mm)
Cargo body 5800×3200×1800(mm),Bottom:16mm, Side:12mm
The curb weight 29400(Kg)
Gross weight 90000 kg
Max. speed 40km/h
Color White, red, green, golden and so on.




Applications:



HOWO 90 Mining Dump Truck is heavy concentrated engineering design personnel and development, first and foremost applies to all kinds of open pit coal mine, steel mills, hydropower construction, dock, poor road conditions, homework is in bad situations in areas within a short distance transport business development of this car, in terms of the particular user groups, with high economic benefit and social benefit.





Competitive Advantage:

1) competive price, cost-effective

2) low fuel consumption
3) strong enough engine
4) with all kinds of truck model, which can fulfil your requirements

5) based on strong technical support and top level technology make the trucks with high quality and more reliable

6) The front lifting type domestic advanced hydraulic control system helps to avoid wrong operation, it has higher

7) the key parts adopt the world's top technology products

8) all kinds of cargo body structure can be designed and produced according to your request, make it have light curb weight , high rigidity , high loading capacity
9) using the high strength steel, make it has a long service life safety and running efficiency.
10) excellant apperance of cabin, safety, reliable
11) quick and efficient spare parts supply bring you more convenient
12) fast delivery time, we can arange production according to your needs exactly and quickly

13) professional import and export dealing precedure, make customs clearance more high efficiency

Sinotruk Howo Mining Tipper Dump Truck 90Tons 6 × 4 High Strength Steel Cargo Body 0Sinotruk Howo Mining Tipper Dump Truck 90Tons 6 × 4 High Strength Steel Cargo Body 1
