20 cbm SINOTRUK HOWO Tipper Dump Truck With 5800 * 2300 * 1500mm Cargo Body

20 cbm SINOTRUK HOWO Tipper Dump Truck With 5800 * 2300 * 1500mm Cargo Body

  • 20 cbm SINOTRUK HOWO Tipper Dump Truck With 5800 * 2300 * 1500mm Cargo Body
  • 20 cbm SINOTRUK HOWO Tipper Dump Truck With 5800 * 2300 * 1500mm Cargo Body
  • 20 cbm SINOTRUK HOWO Tipper Dump Truck With 5800 * 2300 * 1500mm Cargo Body
  • 20 cbm SINOTRUK HOWO Tipper Dump Truck With 5800 * 2300 * 1500mm Cargo Body
20 cbm SINOTRUK HOWO Tipper Dump Truck With 5800 * 2300 * 1500mm Cargo Body
Product Details:
Place of Origin: China
Brand Name: SINOTRUK HOWO
Certification: ISO/3C/BV/IFA/SGS
Model Number: ZZ3257N3847A
Payment & Shipping Terms:
Minimum Order Quantity: 1 Unit
Price: USD40000-USD42000/UNIT)negotiation
Packaging Details: Nude or Waxing in Roro or bulk ship
Delivery Time: 25 working days after received your advance payment
Payment Terms: L/C, T/T, Western Union
Supply Ability: 3,000units per month
Contact Now
Detailed Product Description
Product Name: Tipper Dump Truck Model: ZZ3257N3847A
Drive Type: LHD 6X4 Emission Standard: Euro 2
Engine: WD615.47, 371HP Cargo Body: 5800*2300*1500mm
Loading Capacity: 30-40tons
High Light:

heavy dump truck

,

commercial dump truck

20cbm SINOTRUK HOWO Tipper Dump Truck 25-40Tons for Mining and Municipal works



Description:

20cbm SINOTRUK HOWO Tipper Dump Truck 25-40Tons for Mining and Municipal works

It have the most production quantity, and also is the most famouse brand

to abroad market. It adopts famouse brand VOLVO truck technology.

New HOWO dump truck, High Quality , More Lighter,

SINOTRUK Heavy duty Muck Tipper Dump truck which suitable for public works, for carrying Muck and all kinds of construction material.Especially for public works.

Be comprehensive with Euro2 and Euro3 engine equipped.
Driving type: 4×2, 4×4 6×2, 6×6 ,6×4, 8×4 and so on. Power range: 266HP - 420HP.

It is super art in domestic and abroad auto field, full expression of heavy duty truck concept. Delicate design, excellent technology, which will dazzle you as groundbreaking works

Top configration: Discal brakes +EVB,ABS+ASR+EBL+TPM,More Powerful electronic management system



High Level Comfortable:Cabin 4 point full -floating air suspension ,adjustable steering wheel with various heightsand angles.air suspension seat, Cruise Constant Speed System,MINI Player .electrical control glass and mirror,ATM Gearbox bunk with AC.







Specification:



SINOTRUK HOWO Municipal Heavy Duty Tipper Dump Truck For public work transportation
Model ZZ3257N3847A
Drive Type 6×4
Engine

WD615.47 , 371HP( Euro II)

6 cylinder in-line with water cooling, turbo-charging & inter-cooling,4 stroke electronic fuel injection diesel engine

Displacement : 9.726L

Cabin HW76 lengthened cab(with one sleeper, air-conditioner and new-style seat)
Transmission HW19710(10 forwards & 2 reverses)
Front Axle 1×HF9 ( 9 Tons)
Driving Axle HC16, 16Tons
Steering ZF8118 hydraulic steering with power assistance.
Clutch

Single-plate dry coil-spring clutch, diameter 430mm, hydraulically operating

with air assistance

Rim/ Tire 11.00R20,12.00R20,12.00R24 Radial tire
Wheel base 3800+1350(mm)
Overall dimension 8575×2496×3450(mm)
Cargo body

5800×2300×1500(mm),Bottom:8mm, Side:6mm

The curb weight 12200(Kg)
Gross weight 25000 kg
Max. speed 75km/h
Color White, red, green, golden and so on.




Applications:



It used for Mining industry, Construction business, docks and so on. Especially for public works.



Competitive Advantage:



1) all kinds of cargo body structure can be designed and produced according to your request,

make it have light curb weight , high rigidity , high loading capacity

2) with all kinds of truck model, which can fulfil your requirements

3) professional import and export dealing precedure, make customs clearance more high efficiency

4) using the high strength steel, make it has a long service life

5) strong enough engine

6) low fuel consumption

7) excellant apperance of cabin, safety, reliable

8) quick and efficient spare parts supply bring you more convenient

9) fast delivery time, we can arange production according to your needs exactly and quickly

10) competive price, cost-effective

11) The optimized hydraulic control system helps to avoid wrong operation, it has higher

safety and running efficiency.

12) you can choose cargo body with Front lifting type or Middle lifting type which you prefered

13) The hydraulic sytem using HYVA brand or Domestic famouse brand



20 cbm SINOTRUK HOWO Tipper Dump Truck With 5800 * 2300 * 1500mm Cargo Body 020 cbm SINOTRUK HOWO Tipper Dump Truck With 5800 * 2300 * 1500mm Cargo Body 1
