Dump Truck SINOTRUK HOWO A7 371HP LHD 6X4 25 - 40 tons For Construction Industry

Dump Truck SINOTRUK HOWO A7 371HP LHD 6X4 25 - 40 tons For Construction Industry

  • Dump Truck SINOTRUK HOWO A7 371HP LHD 6X4 25 - 40 tons For Construction Industry
  • Dump Truck SINOTRUK HOWO A7 371HP LHD 6X4 25 - 40 tons For Construction Industry
  • Dump Truck SINOTRUK HOWO A7 371HP LHD 6X4 25 - 40 tons For Construction Industry
  • Dump Truck SINOTRUK HOWO A7 371HP LHD 6X4 25 - 40 tons For Construction Industry
Dump Truck SINOTRUK HOWO A7 371HP LHD 6X4 25 - 40 tons For Construction Industry
Product Details:
Place of Origin: China
Brand Name: SINOTRUK HOWO A7
Certification: ISO/3C/BV/IFA/SGS
Model Number: ZZ3257N3847N1
Payment & Shipping Terms:
Minimum Order Quantity: 1 Unit
Price: USD50000-USD54000/UNIT)negotiation
Packaging Details: Nude or Waxing in Roro or bulk ship
Delivery Time: 25 working days after received your advance payment
Payment Terms: L/C, T/T, Western Union
Supply Ability: 3,000units per month
Contact Now
Detailed Product Description
Product Name: Tipper Dump Truck Model: ZZ3257N3847N1
Drive Type: LHD 6X4 Emission Standard: Euro 2
Cargo Body: 5800*2300*1500mm Loading Capacity: 30-40tons
Highlight:

heavy dump truck

,

sinotruk howo dump truck

Dump Truck SINOTRUK HOWO A7 371HP LHD 6X4 25-40tons for Construction industry



Description:



Dump Truck SINOTRUK HOWO A7 371HP LHD 6X4 25-40tons for Construction industry

Delicate design, excellent technology, which will dazzle you as groundbreaking works. Comfort, safety, reliability, electronic level geared to international level.



Low fuel consumption. Engine output 266-420HP. Euro2-Euro5 emission stand engine.reliable performance and wide acceplication.This model can meet the requirements of severe environment like construction site and mining area.which can fullfiled  you of short distance transportation of mining rock and soil as well as engineering construction.





Specification:



Dump Truck SINOTRUK HOWO A7 371HP LHD 6X4 25-40tons for Construction industry
Model ZZ3257N3847N1
Drive Type 6×4
Engine

WD615.47 , 371HP( Euro II)

6 cylinder in-line with water cooling, turbo-charging & inter-cooling,4 stroke electronic fuel injection diesel engine

Displacement : 9.726L

Cabin A7-W lengthened cab(with one sleeper, air-conditioner and new-style seat)
Transmission HW19710(10 forwards & 2 reverses)
Front Axle 1×HF9 ( 9 Tons)
Driving Axle HC16, 16Tons
Steering ZF8118 hydraulic steering with power assistance.
Clutch

Single-plate dry coil-spring clutch, diameter 430mm, hydraulically operating with

 air assistance

Rim/ Tire 11.00R20,12.00R20,12.00R24 Radial tire
Wheel base 3800+1350(mm)
Overall dimension 8575×2496×3450(mm)
Cargo body 5800×2300×1500(mm),Bottom:8mm, Side:6mm
The curb weight 12200(Kg)
Gross weight 25000 kg
Max. speed 75km/h
Color White, red, green, golden and so on.




Applications:



It suiable for Mining industry, Construction business, docks and so on.



Competitive Advantage:



1)VOLVO cargo body structure , light weight , high rigidity , hight loading capacity

2)Using the high strength steel,it has long service life

3)perfect the sealing structure has the better sealing effect.

4)The advanced hydraulic control system helps to avoid wrong operation, it has higher safety and  running efficiency.

5)the whole truck structure has lower center of gravity,with higher security when lifting the cargo body.

6) beautiful apperance of cabin, safety, reliable

7) lower fuel consumption

8) strong enough power of engine

9)competive price, cost-effective
10)quick and efficient spare parts supply bring you more convenient
11)fast delivery time, we can arange production according to your needs exactly and quickly



Dump Truck SINOTRUK HOWO A7 371HP LHD 6X4 25 - 40 tons For Construction Industry 0Dump Truck SINOTRUK HOWO A7 371HP LHD 6X4 25 - 40 tons For Construction Industry 1
