266HP 10 Wheels Tipper Dump Truck RHD T Type Lifting High Loading Capacity

266HP 10 Wheels Tipper Dump Truck RHD T Type Lifting High Loading Capacity

    • 266HP 10 Wheels Tipper Dump Truck RHD T Type Lifting High Loading Capacity
    • 266HP 10 Wheels Tipper Dump Truck RHD T Type Lifting High Loading Capacity
    • 266HP 10 Wheels Tipper Dump Truck RHD T Type Lifting High Loading Capacity
    • 266HP 10 Wheels Tipper Dump Truck RHD T Type Lifting High Loading Capacity
  • 266HP 10 Wheels Tipper Dump Truck RHD T Type Lifting High Loading Capacity

    Product Details:

    Place of Origin: China
    Brand Name: SINOTRUK HOWO
    Certification: ISO/3C/BV/IFA/SGS
    Model Number: ZZ3257M3247W

    Payment & Shipping Terms:

    Minimum Order Quantity: 1 Unit
    Price: USD38000-USD42000/UNIT)negotiation
    Packaging Details: Nude or Waxing in Roro or bulk ship
    Delivery Time: 25 working days after received your advance payment
    Payment Terms: L/C, T/T, Western Union
    Supply Ability: 3,000units per month
    Contact Now
    Detailed Product Description
    Product Name: Tipper Dump Truck Model: ZZ3257M3247W
    Drive Type: LHD 6X4 Emission Standard: Euro 2
    Engine: WD615.87, 290HP Cargo Body: 5200*2300*1500mm
    Loading Capacity: 30-40tons Lfiting Type: T Type Middle Hydraulic Cylinder
    Thickness Of Cargo Body: Bottom:8mm, Side: 6mm Transmission: HW15710

    Dump Truck SINOTRUK HOWO 266HP 10 Wheels RHD 10-25CBM 30-40tons T type lifting



    Description:



    Dump Truck SINOTRUK HOWO 266HP 10 Wheels RHD 10-25CBM 30-40tons T type lifting

    Since February 2010, two young technical personnel dispatched by truck shares, the 6 consecutive month to travel overseas for more than 10 times, the cumulative held lectures and technical advisory services. Dozens of overseas customer service in Venezuela, two technical personnel in order to better serve users for exporters, they adhere to the "English as the guide, with pictures process for the media, to learn the local language, eliminate communication barriers, constantly learning, improve teaching methods more intuitive, more detailed, and gradually make the Chinese heavy truck overseas users to more accurately grasp the HOWO -A7 products, technical characteristics, structure principle, operation essentials, maintenance tips", as the country's agent. Direct service providers and users soon brought up a convenient localization technology consulting and customer service service team.



    Overseas users heartfelt words through a long-distance telephone, e-mail constantly from the other side of the ocean to China heavy import and export company came. Two technical personnel China heavy duty truck company, with their solid technical strength and sincere service attitude, with Chinese heavy truck 500 HOWO heavy truck arrived in Venezuela, Venezuela by user sincere praise.





    Specification:



    Dump Truck SINOTRUK HOWO 266HP 10 Wheels RHD 10-25CBM 30-40tons T type lifting
    Model ZZ3257M3247W
    Drive Type 6×4
    Engine

    WD615.87 , 290HP( Euro II)

    6 cylinder in-line with water cooling, turbo-charging & inter-cooling,4 stroke electronic fuel injection diesel engine

    Displacement : 9.726L

    Cabin HW76 lengthened cab(with one sleeper, air-conditioner and new-style seat)
    Transmission HW13710(10 forwards & 2 reverses)
    Front Axle 1×HF9 ( 9 Tons)
    Driving Axle HC16, 16Tons
    Steering ZF8118 hydraulic steering with power assistance.
    Clutch

    Single-plate dry coil-spring clutch, diameter 430mm, hydraulically

    operating with air assistance

    Rim/ Tire 11.00R20,12.00R20,12.00R24 Radial tire
    Wheel base 3200+1350(mm)
    Overall dimension 8075×2496×3450(mm)
    Cargo body

    5200×2300×1500(mm),Bottom:8mm, Side:6mm

    The curb weight 12200(Kg)
    Gross weight 25000 kg
    Max. speed 75km/h
    Color White, red, green, golden and so on.




    Applications:



    It used for Mining industry, Construction business, docks and so on.



    Competitive Advantage:



    1) competive price, cost-effective

    2) reliable quality

    3) good after slaes service, which can send engineers for traning and maintainance

    4) all kinds of cargo body structure can be designed and produced according to your request,

    make it have light curb weight , high rigidity , high loading capacity

    5) The optimized hydraulic control system helps to avoid wrong operation, it has higher

    safety and running efficiency.

    6) low fuel consumption

    7) strong enough engine
    8) with all kinds of truck model, which can fulfil your requirements

    9) using the high strength steel, make it has a long service life

    10) fast delivery time, we can arange production according to your needs exactly and quickly

    11) professional import and export dealing precedure, make customs clearance more high efficiency

    12) excellant apperance of cabin, safety, reliable

    13) quick and efficient spare parts supply bring you more convenient

    14) you can choose cargo body with Front lifting type or Middle lifting type which you prefered

    15) The hydraulic sytem using HYVA brand or Domestic famouse brand
