70 Tons HOWO Mining Tipper Dump Truck 6X4 371HP High Strength Steel Cargo Body

70 Tons HOWO Mining Tipper Dump Truck 6X4 371HP High Strength Steel Cargo Body

    • 70 Tons HOWO Mining Tipper Dump Truck 6X4 371HP High Strength Steel Cargo Body
    • 70 Tons HOWO Mining Tipper Dump Truck 6X4 371HP High Strength Steel Cargo Body
    • 70 Tons HOWO Mining Tipper Dump Truck 6X4 371HP High Strength Steel Cargo Body
    • 70 Tons HOWO Mining Tipper Dump Truck 6X4 371HP High Strength Steel Cargo Body
  • 70 Tons HOWO Mining Tipper Dump Truck 6X4 371HP High Strength Steel Cargo Body

    Product Details:

    Place of Origin: China
    Brand Name: SINOTRUK HOWO 70
    Certification: ISO/3C/BV/IFA/SGS
    Model Number: ZZ5707V3840CJ

    Payment & Shipping Terms:

    Minimum Order Quantity: 1 Unit
    Price: USD78000-USD81000/UNIT)negotiation
    Packaging Details: Nude or Waxing in Roro or bulk ship
    Delivery Time: 25 working days after received your advance payment
    Payment Terms: L/C, T/T, Western Union
    Supply Ability: 2,000units per month
    Contact Now
    Detailed Product Description
    Product Name: 10 Wheeler Tipper Truck Model: ZZ5707V3840CJ
    Drive Type: LHD 6X4 Emission Standard: Euro 2
    Engine: D12.42, 420HP Cargo Body: 5800*3100*1600mm, Floor: 16mm, Side: 12mm
    Loading Capacity: 70tons Hydraulic System: HYVA 196 Hydraulic Cylinder


    70Tons HOWO Mining Tipper Dump Truck 6X4 371HP High strength steel cargo body

    Description:

    Tipper Dump Truck SINOTRUK HOWO70 Mining Truck 6X4 420HP 70tons ZZ5707V3840CJ
    HOWO Mining Dump Truck with unilateral high strength skeleton cab, modelling concise, hale and hearty, broaden their horizons; good sealing can ensure your vehicle is always in the safe and comfortable driving environment; there are each of the two lighting lamps at the top of cabin's front and back for night work.

    HOWO-70 mine dump truck is king according to user needs, using the Alison automatic transmission based on mine fighter models, Chelsea PTO, D12.42 heavy duty diesel engine developed Chinese heavy truck, and configuration of high-power cooling system, large flow pump.

    The car's first test car for more than 5 months after the 32700 km mileage of the car proved strong power, strong bearing capacity, quick shift, high reliability, good economic performance, the real implementation of the Dora run, completely suitable for mining operations. The conference, vice principal China Zhongqi Technology Center Ren Guo Jingshun describes the configuration of automatic transmission box HOWO-70 mine dump truck overlord brand planning and product design.



    Specification:


    Tipper Dump Truck SINOTRUK HOWO70 Mining Truck 6X4 420HP 70tons ZZ5707V3840CJ

    Model ZZ5707V3840CJ
    Drive Type6×4
    Engine

    D12.42 , 420HP( Euro II)

    6 cylinder in-line with water cooling, turbo-charging & inter-cooling,4 stroke electronic fuel injection diesel engine

    Displacement : 11.596L

    CabinHW7D   unilateral high strength skeleton cab(with one sleeper, air-conditioner and new-style seat)
    TransmissionHW19710(10 forwards & 2 reverses)
    Front Axle1×HF12 ( 12 Tons)
    Driving AxleAC26, 26Tons
    SteeringZF8118 hydraulic steering with power assistance.
    Clutch

    Single-plate dry coil-spring clutch, diameter 430mm, hydraulically operating
    with air assistance

    Rim/ Tire14.00-25,14.00R25,Radial tire
    Wheel base3800+1500(mm)
    Overall dimension8700×3300×3670(mm)
    Cargo body

    5800×3100×1600(mm),Bottom:16mm, Side:12mm

    The curb weight23000(Kg)
    Gross weight70000 kg
    Max. speed50km/h
    ColorWhite, red, green, golden and so on.


    Applications:

    HOWO 70 Mining Dump Truck is heavy concentrated engineering design personnel and development, first and foremost applies to all kinds of open pit coal mine, steel mills, hydropower construction, dock, poor road conditions, homework is in bad situations in areas within a short distance transport business development of this car, in terms of the particular user groups, with high economic benefit and social benefit.


    Competitive Advantage:

    1) with all kinds of truck model, which can fulfil your requirements
    2) the key parts adopt the world's top technology products
    3) based on strong technical support and top level technology make the trucks with high

    quality and more reliable
    4) all kinds of cargo body structure can be designed and produced according to your request, make it have light curb weight , high rigidity , high loading capacity
    5) using the high strength steel, make it has a long service life
    6) The HYVA brand hydraulic control system helps to avoid wrong operation, it has higher

    safety and  running efficiency.
    7) excellant apperance of cabin, safety, reliable
    8) low fuel consumption
    9) strong enough engine

    10) competive price, cost-effective
    11) quick and efficient spare parts supply bring you more convenient
    12) fast delivery time, we can arange production according to your needs exactly and

    quickly
    13) professional import and export dealing precedure, make customs clearance more high efficiency
