Hydraulic Cylinder HOWO T5G 10 Wheeler Dump Truck With Large Loading Capacity

    • Hydraulic Cylinder HOWO T5G 10 Wheeler Dump Truck With Large Loading Capacity
    • Hydraulic Cylinder HOWO T5G 10 Wheeler Dump Truck With Large Loading Capacity
    • Hydraulic Cylinder HOWO T5G 10 Wheeler Dump Truck With Large Loading Capacity
    • Hydraulic Cylinder HOWO T5G 10 Wheeler Dump Truck With Large Loading Capacity
  • Hydraulic Cylinder HOWO T5G 10 Wheeler Dump Truck With Large Loading Capacity

    Product Details:

    Place of Origin: China
    Brand Name: SINOTRUK HOWO T5G
    Certification: ISO/3C/BV/IFA/SGS
    Model Number: ZZ3257N384GE1

    Payment & Shipping Terms:

    Minimum Order Quantity: 1 Unit
    Price: USD38000-USD42000/UNIT)negotiation
    Packaging Details: Nude or Waxing in Roro or bulk ship
    Delivery Time: 25 working days after received your advance payment
    Payment Terms: L/C, T/T, Western Union
    Supply Ability: 3,000units per month
    Contact Now
    Detailed Product Description
    Product Name: Tipper Dump Truck Model: ZZ3257N384GE1
    Drive Type: LHD 6X4 Emission Standard: Euro 4
    Engine: MC07.34-40, 340HP Cargo Body: 5600*2300*1500mm
    Loading Capacity: 30-40tons Lfiting Type: Front Or Middle Hydraulic Cylinder

    HOWO T5G Dump Truck Euro4 German Man engine 10 Wheels 340HP LHD 30 - 40tons



    Description:



    HOWO T5G Dump Truck Euro4 German Man engine 10 Wheels 340HP LHD 30 - 40tons

    Heavy truck series T5G platform, is based on the introduction of Germany advanced China heavy truck manufacturing technology, combined with the China conditions, to create a standard for transporting high-end card products.



    T5G cab adhering to the style of A7, other power; internal large space, ride comfort, body turning angle is big, easy to to ensure the safety of maintenance; broad vision; the door opened 90 degrees for entry; sleeping about two below the super capacity, storage bin is open to fully meet the needs of long-distance travel; all around the storage space, convenient to put all kinds of daily necessities; the steering wheel can be up and down, before and after adjustment to ensure comfortable driving; four point floating cab can be configured according to the needs of middle seat, suitable for all kinds of short, medium and long distance transportation.750mm wide luxurious sleeper offers comfortable enjoyment for the occupants.



    The T5G platform has three kinds of products Cab can be selected, respectively, M - medium length; W - long and V - long high top three.







    Specification:



    HOWO T5G Dump Truck Euro4 German Man engine 10 Wheels 340HP LHD 30 - 40tons
    Model ZZ3257N384GE1
    Drive Type 6×4
    Engine

    MC07.34-40, 340HP( Euro 4)

    6 cylinder in-line with water cooling, turbo-charging & inter-cooling,4 stroke electronic fuel injection diesel engine

    Displacement : 9.726L

    Cabin T5G-M lengthened cab(with one sleeper, air-conditioner and new-style seat)
    Transmission HW15710(10 forwards & 2 reverses)
    Front Axle 1×HF7 ( 7 Tons)
    Driving Axle HC16, 16Tons
    Steering ZF8118 hydraulic steering with power assistance.
    Clutch

    Single-plate dry coil-spring clutch, diameter 430mm, hydraulically

    operating with air assistance

    Rim/ Tire 11.00R20,12.00R20,12.00R24 Radial tire
    Wheel base 3800+1350(mm)
    Overall dimension 8375×2496×3450(mm)
    Cargo body

    5600×2300×1500(mm),Bottom:12mm, Side:10mm

    The curb weight 12200(Kg)
    Gross weight 25000 kg
    Max. speed 75km/h
    Color White, red, green, golden and so on.




    Applications:



    It used for Mining industry, Construction business, docks and so on.



    Competitive Advantage:



    1) German MAN engine technology

    2) long quality warranty

    3) reliable quality

    4) good after slaes service, which can send engineers for traning and maintainance

    5) low fuel consumption

    6) strong enough engine
    7) with all kinds of truck model, which can fulfil your requirements

    8) using the high strength steel, make it has a long service life

    9) competive price, cost-effective

    10) fast delivery time, we can arange production according to your needs exactly and quickly

    11) professional import and export dealing precedure, make customs clearance more high efficiency

    12) all kinds of cargo body structure can be designed and produced according to your request,

    make it have light curb weight , high rigidity , high loading capacity

    13) The optimized hydraulic control system helps to avoid wrong operation, it has higher

    safety and running efficiency.

    14) excellant apperance of cabin, safety, reliable

    15) quick and efficient spare parts supply bring you more convenient

    16) you can choose cargo body with Front lifting type or Middle lifting type which you prefered

    17) The hydraulic sytem using HYVA brand or Domestic famouse brand



    Hydraulic Cylinder HOWO T5G 10 Wheeler Dump Truck With Large Loading CapacityHydraulic Cylinder HOWO T5G 10 Wheeler Dump Truck With Large Loading Capacity
